- 14 -
• English
Operating Instructions 2.0COSMO Line Array – Instructions for use
4 Controller Settings
The following fi lters are available for operating the system’s
components with Lake and Armonía controller software.
Filters for COSMO M/H units
C 6
"C 6 – FR" (Fullrange) "C 6 – LC" (Low Cut)
C 8
"C 8 – FR" (Fullrange) "C 8 – LC" (Low Cut)
C 10
"C 10 – 60° FR" (Fullrange) "C 10 – 60° LC" (Low Cut)
"C 10 – 80° FR" (Fullrange) "C 10 – 80° LC" (Low Cut)
Filters for C SUB subwoofers
CF 118
"CF 118 – Flat" "CF 118 – Boost" "CF 118 – Sub Low"
CS 118
"CS 118 – Flat" "CS 118 – Boost" "CS 118 – Sub Low"
CS 218
"CS 218 – Flat" "CS 218 – Boost" "CS 218 – Sub Low"
CS Flat: for large arrays with 12 or more M/H units
CS Boost: for small arrays with up to 12 M/H units
or for ground stacks
CS Sub Low: for CF 118, CS 118 and CS 218 sub low add-ons
If you wish to use Lake, there are also compensation overlays
(fi lters) available for arrays of varying lengths:
EQ array compensation overlays
6 to 8 cabinets 9 to 11 cabinets 12 to 20 cabinets
4.1 Recommended fi lters
COSMO mid/high units and C SUB series subwoofers are designed
for the most diverse applications. Use the recommended fi lter to
adapt them to the given application. These EQ setups have been
tested and proven.
• Standalone M/H units:
The recommendation for mid/high units deployed as standalone
units such as near-fi lls and the like is to activate each unit’s low-
cut fi lter.
• M/H unit array:
The recommendation for arrays consisting of just one type of mid/
high unit – that is, setups consisting solely of C 6, C 8 or C 10 cabi-
nets – is to active the fullrange preset for each cabinet.
Lake: Be sure to select the right EQ overlay for the given number
of deployed mid/high units when using Lake.
Armonía: It provides ready-to-use modules with compensation
built in, so you do not need to select the appropriate EQ overlays
in Armonía.
• Arrays with added subwoofers:
We recommend the following fi lter combinations for arrays with
added C SUB bass bins::
C 6 / C SUB
for "CS Flat" or "CS Sub Low" "C 6 – FR"
for "CS Flat" or "CS Boost" "C 6 – LC"
C 8 / C SUB
for "CS Flat" or "CS Sub Low" "C 8 – FR"
for "CS Flat" or "CS Boost" "C 8 – LC"
C 10 / C SUB
for "CS Flat" or "CS Sub Low" "C 10 – FR"
for "CS Flat" or "CS Boost" "C 10 – LC"
We recommend the following
M/H-unit-to-subwoofer ratios:
Three C 6 / C 8 to two CS/CF 118
Three C 6 / C 8 to one CS 218
Two C 10 to two CS/CF 118
Two C 10 to one CS 218
4 Controller Presets
