Operating Instructions 2.0COSMO Line Array – Instructions for use
Connecting subwoofers
Connect no more than two CS 118/CF 118 (or one CS218 unit) to
each channel. The recommended minimum electrical impedance
for each channel is 4 ohms.
CH 1
MADE IN GERMANY
CH 1: 1+/–
CH 2: 2+/–
CH 2: 1+/–
CH 1: 2+/–
Lift
Ground
CH 2
Lift
Ground
CH 3
Lift
Ground
CH 4
1/2
CH
1/2
CH 3: 1+/–
CH 4: 2+/–
CH 4: 1+/–
CH 3: 2+/–
1+/– 2+/– 3+/– 4+/–
CH
3/4
CH
1/2/3/4
3/4
Lift
Ground
PB-8
Analog In AES3
1
2
Ethernet Amp Out
Amp Out
Parallel OutThru
2 143
CH 1 CH 2 CH 3 CH 4
2+/–
LF signal
Using the COSMO multicore cable
• LSM Mid/High adapter (art. no. 1006166)
The LSM Mid/High adapter is a convenient way of connecting
larger systems. The LSM Mid/High adapter's NL4 pin assignments
are two poles to pin 1+/–. See section 5,"Example Setups," for
more on this.
NLT8MX
NL4
NL4
NL4
NL4
0.60 m
1.20 m
2.00 m
2.60 m
• LSM Sub adapter (art. no. 1006167)
The LSM Sub adapter is a convenient way of connecting larger
systems. The LSM Sub adapter's NL4 pin assignments are two
poles to pin 2+/–. The subwoofer's Pin Assignment switch has to
set to the 2+/– position.
NLT8MX
NL4
NL4
NL4
NL4
5.00 m
5.00 m
5.00 m
5.00 m
LSM Sub 2+/–
• NL8 Multicore
LSM 5 (art. no. 1007712) length 5 m
LSM 10 (art. no. 1007713) length 10 m
LSM 15 (art. no. 1007714) length 15 m
LSM 20 (art. no. 1006165) length 20 m
NLT8FX NLT8FX
3 Connectors and Speaker Cables
