– 6 –
NAMES AND FUNCTIONS OF REMOTE CONTROL UNIT
REMOTE CONTROLLER
This controls the operation of the indoor unit. Signal range to reach indoor unit is about 7 meters. If
inverter lamp is used, the range of control may be shorter.
This unit can be fi xed on a wall using the fi xture provided. Before fi xing it, make sure the indoor unit
can be controlled from the remote controller.
● Transmission sign
The transmission sign blinks when a signal is sent.
● Display
This indicates the room temperature selected, timer status, function
and intensity of circulation selected.
● AIR SLEEP TIMER button
Use this button to set the air sleep timer mode.
● TEMPERATURE button
Use this button to raise or lower the temperature setting. (Keep pressed,
and the value will change more quickly.)
● START/STOP button
Press this button to start or to stop operation.
● FAN SPEED selector button
This determines the fan speed. Each time you press this button, the
intensity of circulation will change from (AUTO)
➞
(HI)
➞
(MED)
➞
(LOW)
➞
(SILENT).
● AUTO SWING button
Controls the angle of the horizontal air defl ector.
● REFRESH button
Use this button to refresh the room condition.
● RESET button
● ONE TOUCH POWERFUL buttonA
Use this button to deliver faster and more comfortable air-conditioning
or start operation.T
● FROST WASH button
During OFF mode, press this button to set the Frost Wash operation.
● OFF-TIMER button
Select to turn OFF time.
● ON-TIMER button
Select to turn ON time.
● MODE selector button
Use this button to select MODE. Each time you press this button the
MODE selection will change from
(COOLING)
➞
(SILENT)
➞
(DEHUMIDIFY)
➞
(FAN).
However, during OFF mode SILENT will be skipped.
Precautions for Use
● Do not put the remote controller in the following places.
● In direct sunlight.
● In the vicinity of a heater.
● Handle the remote controller carefully. Do not drop it on the
fl oor, and protect it from water.
● Once the outdoor unit stops, it will not restart for about 3
minutes (unless you turn the power switch off and on or unplug
the power cord and plug it in again).
This is to protect the device and does not indicate a failure.
