46
2
1
Preparation before use
The floor should be sturdy and flat.
Lay a board with 1cm thickness on the floor if the refrigerator is
installed on the carpet, tatami mat, flooring or PVC sheet flooring
which may be hollow or discolor.
Place the refrigerator away from direct sunlight and heat.
This will reduce adverse effects to refrigerating power and keep
electricity cost down.
Do not place it in damp areas, and ensure good air ventilation.
This will prevent rust and condensation.
The refrigerator should be separated from other equipment
such as TVs.
This is to prevent disturbance (noise / scattered image) to TVs
and other devices caused by the refrigerator.
●
●
●
●
●
Packaging specifications may vary depends on
production time, but this does not affect the quality.
●
Depending on the strength and type of the floor
material, and the weight of the food, the door may
lower several days later (about 5 days). In this case,
adjust the doors to be parallel again.
●
If the place where the refrigerator is installed
is not horizontal or the floor material is soft,
there may be a height difference between the
left and right doors of the refrigerator.
There is no problem with the functioning of
the refrigerator, but if you are concerned,
adjust the doors to be paralleled by following
the above described procedure.
●
If you make the refrigerator horizontal left to right
but make the front slightly higher than the back,
it will be easier to close the doors and the doors
will be less likely to remain partially open.
●
When you release your hand from a refrigerator
door with the door open, the door may move.
But this is normal.
Note
Adjust and fix the refrigerator horizontally.
As a guide, the height of the door can be adjusted 1mm every one turn of the adjustable mount.
If the adjustable leg is difficult to turn, insert a Phillips screwdriver to turn it.
Turn the left and right adjustable mounts until they touch the floor.
Adjust so that the left and right doors of the refrigerator compartment are parallel.
Hold the leg cover and pull it toward you to remove it.
1
3
Insert the fork of the leg cover into the mounting holes to attach the cover.
4
Place cushions under the adjustable mounts.
Place the cushions under the adjustable mounts evenly at the front, back, left and right.
2
Cushion
■
The left side door is lower
Turn the left adjustable mount clockwise to level
the left and right doors.
■
The right side door is lower
Turn the right adjustable mount clockwise to level
the left and right doors.
Recommended size of Phillips screwdriver
Approx.10 cm
Approx.
φ
0.6 cm
Phillips screwdriver
Insert the Phillips screwdriver securely into the
groove of the adjustable mount and then turn it.
Use the supplied cushion [2 pc]
●
Always wipe the adjustable mounts and clean the floor before placing the cushions.
Any dirt under the cushions may scratch the floor.
●
●
Be careful not to scratch the floor with the Phillips screwdriver
when turning the adjustable mount.
Excessively turning an adjustable mount may cause it to detach.
BEFORE USE
Above 5 cm or more
Left and right 0.5 cm or more
When installing the refrigerator near the wall, please allow
a gap of 1.5 cm or more between the refrigerator and the wall.
(Otherwise, the refrigerator doors may not open fully and the
food/cases in the refrigerator may not be taken out.)
When the refrigerator doors are hard to open, please move
the refrigerator further away from the wall.
*
The actual size of the center part of the side of the refrigerator's
main body is slightly larger than the nominal size.
Therefore, please allow sufficient space around the refrigerator when installing it.
*
If you are concerned about noise caused by vibration or condensation on
the rear of the refrigerator or discoloration/marking on the wall due to
high humidity, install the refrigerator with a gap of 2 cm or more.
Please allow sufficient space around the refrigerator to dissipate heat
generated from the refrigerator as shown in the illustration on the right.
●
Leg cover
Cushion (Supplied tool)
Adjustable mount
Phillips screwdriver
Phillips screwdriver
Fork
Leg cover
Mounting holes
