CHINESE WATER SUPPLY HOSE CONNECTION
1. Select a suitable tap with a tip length greater than 10 mm. The outlet end must be flat. If it is uneven,
smooth it out with a file to prevent leakage after installation (see Figure 1).
2. Push the slider down to disconnect the water supply hose connector from the inlet assembly (see Figure 2).
3. Loosen the four screws on the water supply hose connector, then attach the hose to the tap. If the tap
diameter is too large for the connector, loosen the screws and remove the sleeve (see Figure 3).
4. Evenly tighten the four screws on the water supply hose connector and secure the nuts (see Figure 4).
5. If the appliance is to be used once or several times in a week, push the slider down without disconnecting
the water supply hose connector to avoid damaging the fixing screws.
Correct
size
Outlet end
Water supply
hose connector
Slider
Water supply hose
Screwdriver
Screw
Sleeve
Nut
Before tightening:
~ 4 mm; After
tightening: < 2 mm.
NOTE: The exposed thread length before tightening the nut is approximately 4 mm and less than 2 mm
after tightening (Figure 4).
AQUASTOP CONNECTION
If an internal tube or hose is damaged, a shut-off system is activated that cuts the water supply to the
appliance. In such case, the control glass (a) will turn red. Replace the water supply hose.
Do not dip the water supply hose with the AquaStop system in water as it contains an electric
valve.
The water supply hose can be connected without a non-return valve.
16
