20
6. PRODUCT INSTALLATION
Selection of Installation Equipment
Cut out the work surface according to the sizes shown in the drawing.
For installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure
the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated
work surface material (Wood and similar fibrous or hygroscopic material shall not be used as
work
surface material unless impregnated) to avoid the electrical shock and larger deformation
caused by
the heat radiation from the hotplate. As shown below:
Note: The safety distance between the sides of the hob and the inner surfaces of the
worktop should be at least 3mm.
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
F(mm)
800
520
48
44
750+2
480+2
50 min.
3 min.
Under any circumstances, make sure the Induction cooker hob is well ventilated and the air inlet
and outlet are not blocked. Ensure the induction cooker hob is in good work state. As shown
below.
Note: The safety distance between the hotplate and the cupboard above the hotplate
should be at least 500 mm.
A(mm)
B(mm)
C(mm)
D
E
500
15 min.
20 min.
Air intake
Air exit 5mm
WARNING: Ensuring Adequate Ventilation
Min.30mm
