Hisense HFC743169BKA handleiding
Handleiding
Je bekijkt pagina 31 van 126
For easier transport, some of the appliance's parts are packed separately and placed securely in the main packaging compartment. //
Before first use, read and follow the instructions for assembly and safe use. // The appliance is intended for household use.
PARTS
1
Housing with the motor, battery and dust container
2
Floor cleaner suction hose
3
Vacuum cleaner suction hose
4
Motorised floor brush for floor cleaner
5
Motorised floor brush for vacuum cleaner
6
Motorised brush for vacuuming fabric surfaces
7
Stand for vacuum cleaner, cleaner, and other attachments
8
Soft bristle brush
9
Longer crevice nozzle
10
Bristle brush
11
Power cord for the stand
12
Adapter with power cord
13
Cleaning brush
INSTALLATION
Attach the suction hose of the floor cleaner to the floor cleaner brush. // Slide the motor housing onto the floor cleaner suction
hose. // Installation is correct when the appliance is secured in the grooves (it snaps into place at all settings).
Assemble the stand as shown in the images. // Installation is correct when the appliance is secured in the grooves (it snaps
into place at all settings). // Insert the power cord for the stand on the back of the bracket on which the floor cleaner will be
mounted.
Put all attachments on the stand. // The floor cleaner is correctly positioned when it is attached to the charging port.
The charging station should be at least 1 m away from any heating elements.
CHARGING
Charge the appliance at least 1 m away from any heating surfaces. // The appliance cannot be switched on while charging.
Place the floor cleaner on the charging station to charge it. // At the back, plug in the power cord that is included with the kit.
// In this case, do not switch on the adaptor. // Battery charge is displayed on the motor unit display.
You can also charge the battery of the vacuum cleaner when it is used only for vacuuming. // An adapter with a power cord
is included in the kit. // By pressing the button on the vacuum cleaner battery, you can safely remove the battery, which can
also be charged separately from the vacuum cleaner itself. // During charging, the battery percentage level will appear on
the display.
DISPOSAL OF THE APPLIANCE
If you want to replace the appliance or you no longer need it, you should also think about protecting the environment.
The battery must be removed before disposing of the vacuum cleaner. // To safely remove the battery, make sure that the
battery is completely discharged. If the appliance does not have a removable battery, please follow the instructions in the
booklet.
OPERATION
Description of the cleaner and vacuum cleaner display
1
Roller self-cleaning button. // It is operational when the stand is connected to the mains and the cleaner is correctly
installed on the stand. // The function is enabled only when the motor unit is mounted on the floor cleaner.
2
Button for dispensing/spraying water on a hard floor. // This function allows you to control the wetness of the floor
during cleaning. // It is operational only when the floor cleaner is in use.
3
ON/OFF button. // When the cleaner is placed in an upright position, it will stop automatically.
4
Speed control button. Operation: ECO (up to 20 min) / Auto (up to 25 min).
5
Display:
Speed control
Battery charge status in digital format
Clean water reservoir empty symbol. / Fill the container.
Dirty water reservoir full symbol. / Empty the container.
Self-cleaning symbol.
Roller drying symbol.
The dirty water reservoir is not installed.
The air supply is blocked. Clean the hose or brush.
Floor cleaner
The floor cleaner is intended for washing hard floor surfaces. It is not suitable for washing flammable products, glass or
flammable liquids as it can damage the appliance or even cause it to catch fire. // While the cleaner is upright, it is in the
standby position and will shut off if you put it in this position. // To start, tilt the appliance to an angle enabling you to switch
it on and start cleaning the floor. // To dispense water, press the button on the motor unit as required. // Operation: ECO (up
to 20 min) / AUTO (up to 25 min). The display on the motor unit shows various functions. Each function is shown in the table.
// Rollers on the floor brush allow you to clean dirty floors and at the same time collect water and dirt and dry the floor.
31
