14
！
危 险
！
●With tape material along the wire wrapped, sealed wiring holes, prevent the condensed water and insects.
●Tightly secure the power source wiring by using the cord clamp inside the unit.
General Check
(1) Make sure that the field-selected electrical components (main power
switches, circuit breakers, wires, conduit connectors
and wire terminals) have been properly selected according
to the electrical data.
Make sure that the components comply with National Electrical
Code (NEC).
(2) Check to ensure that the voltage
of power supply is within 10% of nominal voltage and earth phase is contained in the
power supply wires. If not, electrical
parts will be damaged.
(3) Check to ensure that the capacity
of power supply is enough.
If not, the compressor will not be able to operate because of abnormal voltage drop at starting.
(4) Check to ensure
that the earth
wire is connected.
(5) Install a main switch, multi-pole
main switch with a space of 3.5mm or more, single phase main switch with a space of
3.0mm or more between phases.
(6) Check
to ensure that the electrical resistance
is more than 2MΩ, by measuring the resistance between ground and the
terminal of the electrical parts. If not,
do not operate the system until the electrical leakage is found and repaired.
● Turn OFF the main power switch of the indoor unit and the outdoor unit and wait for more than 3 minutes before
electrical wiring work or a periodical check is performed.
● Check to ensure that the indoor fan and the outdoor fan have stopped before electrical wiring work or a periodical check
is performed.
● Protect the wires, electrical parts, etc. from rats or other small animals. If not protected, rats may gnaw at unprotected
parts and at the worst, a fire will occur.
●Avoid the wiring from touching the refrigerant pipes, plate edges and electrical parts inside the unit.
If not do, the wires will be damaged and at the worst, a fire will occur.
●Install an ELB (Electric Leakage Break) in the power source.
If ELB is not used, it will cause electric shock or fire at the worst.
●This unit uses an inverter, which means that it must be used an earth leak detector capable of handing harmonics in order
to prevent malfunctioning of the earth leak detector itself.
● Do not use intermediate connection wires, stranded wires (see <Attentions when Connecting the Power Supply
wiring>), extension cables or control line connection, because the use of these wires may cause fever, electric shock
or fire.
●The tightening torque of each screw is shown as follows.
M4: 1.0 to 1.3 N·m
M5: 2.0 to 2.5 N·m
M6: 4.0 to 5.0 N·m
M8: 9.0 to 11.0 N·m
M10: 18.0 to 23.0 N·m
Keep the above tightening torque during wiring work.
WARNING
CAUTION
Additional refrigerant charge
The unit has been filled with refrigerant.
Please calculate additional charge according to “Piping Requirement”.
After finishing vacuum pump procedures, first exhaust air from charge hose, then open valves, charge refrigerant
through liquid stop valve.
At the end, please close valves and record the refrigerant charge quantity.
Wiring
Installation instructions
NOTE: Fix the rubber bushes with adhesive when conduit tubes to the outdoor unit are not used.
