California Proposition 65
WARNING
Carcinogenic, risk of birth defects or other reproductive harm. This product can expose you to chemicals including lead and lead
compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
▶ For more information go to www.p65warnings.ca.gov .
This warning is applicable only for the State of California, USA.
Description
Product overview 1
@
Vibratory poker
;
Protective hose
=
On/off switch
%
Power cord
&
Supply cord plug
Intended use
The product described is an internal vibrator. It is designed for compacting fresh concrete.
Use the internal vibrator only in combination with the NCV 10-22 portable power supply unit from Hilti.
The vibratory poker must be submerged into the fresh concrete.
Do not dip the vibratory poker into acidic or alkaline liquids.
Do not bring the vibratory poker into contact with or insert it into parts of the body.
Working principle,
The product is an internal vibrator with an electric motor built into the vibratory poker that drives an unbalanced mass to produce gyrations. By
means of these gyrations, the vibratory poker introduces vibrations into the concrete. Submerging the vibratory poker into the fresh concrete
causes de-aeration and compaction of the fresh concrete within the area of influence of the vibratory poker. At the same time, the fresh concrete
cools the vibratory poker.
Items supplied
Internal vibrator, operating instructions
Other system products approved for use with this product can be found at your local Hilti Store or at: www.hilti.group
Technical data
Product properties
NCV 38 / NCV 1.5 NCV 45 / NCV 1.75 NCV 58 / NCV 2.25
Weight NCV x 1500 / NCV x 5
4.3 kg
(9.5 lb)
5.5 kg
(12.1 lb)
8.1 kg
(17.9 lb)
NCV x 3000 / NCV x 10
5.3 kg
(11.7 lb)
6.5 kg
(14.3 lb)
9.7 kg
(21.4 lb)
NCV x 5000 / NCV x 16
6.7 kg
(14.8 lb)
7.9 kg
(17.4 lb)
11.9 kg
(26.2 lb)
Rated current
5.0 A 8.0 A 12.0 A
Rated voltage
42 V 42 V 42 V
Rated frequency
200 Hz 200 Hz 200 Hz
Power rating
0.29 kW 0.47 kW 0.70 kW
Vibration amplitude in air
2.0 mm
(0.08 in)
2.3 mm
(0.09 in)
2.9 mm
(0.11 in)
Vibrations
12,000 /min at 200 Hz 12,000 /min at 200 Hz 12,000 /min at 200 Hz
Diameter, vibratory poker
38 mm
(1.5 in)
45 mm
(1.8 in)
58 mm
(2.3 in)
Outside diameter, protective hose
31 mm
(1.2 in)
31 mm
(1.2 in)
40 mm
(1.6 in)
Length, protective hose NCV x 1500 / NCV x 5
1.5 m
(4 ft - 11.1 in)
1.5 m
(4 ft - 11.1 in)
1.5 m
(4 ft - 11.1 in)
NCV x 3000 / NCV x 10
3.0 m
(9 ft - 10.1 in)
3.0 m
(9 ft - 10.1 in)
3.0 m
(9 ft - 10.1 in)
NCV x 5000 / NCV x 16
5.0 m
(16 ft - 4.9 in)
5.0 m
(16 ft - 4.9 in)
5.0 m
(16 ft - 4.9 in)
Length, vibratory poker
295 mm
(11.6 in)
332 mm
(13.1 in)
340 mm
(13.4 in)
Length, power cord
0.8 m … 1.1 m
(2 ft - 7.5 in …
3 ft - 7.3 in)
0.8 m … 1.1 m
(2 ft - 7.5 in …
3 ft - 7.3 in)
0.8 m … 1.1 m
(2 ft - 7.5 in …
3 ft - 7.3 in)
