For Type III and Type V camera:
i. Use three PM4 screws to fix the installation plate
onto the wall mount.
Figure 2-13 Fix the Installation Plate
For Type IV camera:
i. Refer to Step 3 of Section 2.2.1 to dissemble the
camera
ii. Use M4 × 10 screws to fix the base onto the wall
mount.
Figure 2-14 Fix the Base
4. Refer to Steps 3 to 5 of Section 2.2.1 to finish
installation.
Figure 2-15 Finish Installation
3 Waterproof Measures
If the camera is installed outdoor, you should use the
waterproof tapes to waterproof the cables. Otherwise
the cables might get wet or a short circuit occurs.
Note:
Waterproof tapes should be purchased separately.
After routing and connecting the cables, use the
waterproof tapes to wrap up the cables. Connected
cables and spare cables both should be wrapped up as
the figures below.
