English
9
SPECIFICATIONS
1. Power tool
The specifications of this machine are listed in the
Table on page 20.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
2. Battery
Model Voltage Battery capacity
BCL320 3.6 V 2.0 Ah
EBM315 3.6 V 1.5 Ah
CHARGING
Before using the power tool, charge the battery as follows.
<UC3SFL>
1. Connect the charger’s power cord to the
receptacle.
2. Insert the battery into the charger.
Firmly insert the battery into the charger till it contacts
the bottom of the charger and checking the polarities as
shown in Fig.3.
3. Charging
Inserting the battery will turn on the charger (the pilot
lamp lights up).
The pilot lamp goes off to indicate that the battery is
fully charged.
NOTE
○ If the red lamp does not light up even after the charger
has been attached, check to confirm that the battery
has been fully inserted.
○ Battery overheated. Unable to charge.
Although charging will start once the battery has cooled
down even when left in situ, the best practice is to
remove the battery and allow it to cool down in a
shaded, well-ventilated location before charging.
○ When the battery charger has been continuously used,
the battery charger will be heated, thus constituting the
cause of the failures. Once the charging has been
completed, give 15minutes rest until the next charging.
(1) Regarding the temperatures and charging time of the
battery. (See Table1)
Table 1
Model UC3SFL
Type of battery Li-ion
Charging voltage 3.6 V
Temperatures at which the
battery can be recharged
0°C–50°C
Charging time for
battery capacity,
approx. (At 20°C)
1.5Ah 30min
2.0Ah 40min
Number of battery cells 1
Weight 0.3kg
NOTE
○ The recharging time may vary according to the ambient
temperature and power source voltage.
○ If charging takes a long time
– Charging will take longer at extremely low ambient
temperatures. Charge the battery in a warm location
(such as indoors).
4. Disconnect the charger’s power cord from the
receptacle.
5. Hold the charger firmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after
use, and then keep it.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries and
batteries that have not been used for an extended period is
not activated, the electric discharge might be low when
using them the first and second time. This is a temporary
phenomenon, and normal time required for recharging will
be restored by recharging the batteries 2–3 times.
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted. When you feel that the power of the tool
becomes weaker, stop using the tool and recharge its
battery. If you continue to use the tool and exhaust the
electric current, the battery may be damaged and its life
will become shorter.
(2) Avoid recharging at high temperatures. A rechargeable
battery will be hot immediately after use. If such a
battery is recharged immediately after use, its internal
chemical substance will deteriorate, and the battery life
will be shortened. Leave the battery and recharge it
after it has cooled for a while.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery 4 2
Selecting the lock switch position*
1
5 2
Change rotation speed*
2
6 3
Tightening torque adjustment*
3
7 3
Selecting the drill position 8 3
Mounting and dismounting of the bit*
4
9 3
Switch operation *
5
10 3
How to use the LED light 11 3
Auto Shut Off function*
6
12 4
Use as a manual screwdriver*
7
13 4
Selecting accessories — 22
*1 Selecting the lock switch position
CAUTION
In the following situations, be sure to put the lock switch
in the Lock ( ) position.
○ When not using the tool
○ When attaching or removing the bit
○ When using the tool as a manual screwdriver
*2 Change rotation speed
