10
GB
• Operating the appliance for any other purpose shall be
deemed as a misuse of the device. The user shall be solely
liable for improper use of the device.
Grounding installation
This appliance is classified as protection class I and must be
connected to a protective ground. Grounding reduces the risk
of electric shock by providing an escape wire for the electric
current.
This appliance is fitted with a power cord with grounding plug
or electrical connections with grounding wire. The connec
-
tions must be properly installed and grounded.
Main parts of the product
(Fig.1 on page 3)
1. Protective cover
2. Cover cap
3. Jug lid
4. Jug
5. Blade assembly
6. Motor base
7. Control panel
Remark: The content of this manual applies for all listed
items unless specified otherwise. The appearance may vary
from the shown illustrations.
Control panel
(Fig.2 on page 4)
8. Power switch (ON/ STANDBY): Press to switch ON the ma-
chine; Press again to switch to STANDBY mode
9.
Speed control: Select and then press to the desired speed.
9a. Low
9b. Medium
9c. High
10. Timer: Select and then press to the desired time (30s /
45s / 90s)
11. Pulse button: Full speed impulse movement. Press and
hold to operate, release the button to stop.
12. Digital control display
Circuit diagram
(Fig.3 on page 4)
A. Micro switch (16A/250V)
B. Main PCB
C. Magnetic safety micro switch (10A/250V)
D. Digital control PCB
Exploded diagram with part list
(Fig.4 on page 5)
Part no. Part name Quantity
1 Cap cover 1
2 Jug lid 1
3 Stamper (not supplied) 1
4 Protective cover (rear) 1
5 Jug set 1
6 Protective cover rubber sealing (rear) 1
7 Blade assembly 1
8 Seal ring of the blade assembly 1
9 Large seal ring 1
10 Mounting screw 1
11 Clutch 1
12 Jug holder 1
13 Jug holder support 1
14 Rubber seal cover 1
15 Motor outer housing 1
16 Safety micro switch assembly 1
17
Internal wire terminal for
safety micro switch
1
18 Mounting screws for the micro switch 2
19 Power plug 1
20 Power cord 1
21 Power cord clamp 1
22 Motor assembly 1
23 Motor inner housing 1
24 Bottom housing 1
25 Bottom plate 1
26 Fixing screw 4
27 Protective cover (front) 1
28 Protective cover (inner) 1
29 Jug handle left cover 1
30 Jug handle right cover 1
31 Control panel PCB 1
32 Control panel inner cover 1
33 Touch plate 1
34 Control panel outer cover 1
35 Anti-shock dampers 4
36
Mounting screws for an
-
ti-shock dampers
4
37 Magnetic micr
o switch assembly 1
38
Internal wire terminal for
the magnetic switch
1
39 PCB assembly 1
40 Screws for fixing PCB assembly 2
41 Sound absorption cotton 1
Preparation before use
• Remove all protective packaging and wrapping.
• Check that the device is in good condition and with all
accessories. In case of incomplete or damaged delivery,
please contact the supplier immediately. In this case, do not
