19
9530-10
The proper setting depends on the job and the
type of bit, fastener, and the material you will
be working on. In general, use greater torque
for larger screws. If the torque is too high, the
screws may be damaged or broken.
Your drill features 18 torque settings for
driving and 1 drilling setting. Output torque
will increase as the ring is rotated from 1 to 18.
Adjust the torque by rotating the torque-
adjustment ring. The higher the torque
setting, the more force the tool produces to
turn an object.
The drilling setting
will lock the clutch
to permit drilling and other heavy-duty
applications.
LED light (see figure M)
Your tool is equipped with an LED light 5,
located on the base of the tool. This provides
additional light on the surface of the work
piece for operation in lower-light areas.
The LED light 5 will automatically turn on
with a slight squeeze on the variable-speed
trigger switch 4 before the tool starts running,
and will turn off approximately 10 seconds
after the variable-speed trigger switch 4 is
released.
The LED light will rapidly flash when the tool
and/or battery pack becomes overloaded or
too hot, and the internal sensors will turn the
tool off. Rest the tool for a while or place the
tool and battery pack separately under air
flow to cool them.
The LED light will flash more slowly to
indicate that the battery is at low-battery
capacity. Recharge the battery pack.
Switching on the power tool (see
figure N)
■
To switch the power tool on:
Press the trigger switch 4.
The variable-speed trigger switch delivers
higher speed with increased trigger pressure
and lower speed with decreased trigger
pressure.
■
To switch the power tool off:
Release the trigger switch 4.
WARNING!
To prevent accidental starting that could
cause serious personal injury, always
remove the battery pack from the tool when
assembling parts.
WARNING!
If any parts are damaged or missing, do
not operate this product until the parts are
replaced. Use of this product with damaged
or missing parts could result in serious
personal injury.
Drilling (see figure O)
WARNING!
Always wear safety goggles or safety
glasses with side shields during power
tool operation or when blowing dust. If
operation is dusty, also wear a dust mask.
a. Check that the direction preselector
switch 7 is at the correct setting (forward
or reverse).
b. Secure the material to be drilled in a vise
or with clamps to keep it from turning as
the drill bit rotates.
c. Hold the drill firmly and place the bit at
the point to be drilled.
d. Depress the variable-speed trigger
switch 4 to start the drill.
e. Move the drill bit into the workpiece,
applying only enough pressure to keep
the bit “biting”. Do not force the drill or
apply side pressure to elongate a hole.
Let the tool do the work.
f. When drilling hard, smooth surfaces,
use a center punch to mark the desired
location of the hole. This will prevent the
drill bit from slipping off-center as the
hole is started.
g. When drilling metals, use light oil on
the drill bit to keep it from overheating.
The oil will prolong the life of the bit and
increase the drilling efficiency.
h. If the bit jams in the workpiece or if the
drill stalls, stop the tool immediately.
Remove the bit from the workpiece and
determine the reason for jamming.
There are two rules for drilling hard materials.
First, the harder the material, the greater
the pressure you need to apply to the tool.
Second, the harder the material, the slower
the speed should be. If the hole to be drilled
is large, drill a smaller hole first, and then
enlarge to the required size with a larger bit;
it’s often faster in the long run.
