Je bekijkt pagina 16 van 200
16
[
+49 (0) 21 91 / 7 92-0 •
^
hazet.de •
]
info@hazet.de
16
9513-2100
Operating instructions
WARNING!
Remove the battery before carrying out any
work on the power tool.
Before switching on the power
tool
Unpack the cordless impact wrench and check
that here are no missing or damaged parts.
NOTE
The batteries are not fully charged on delivery.
Prior to initial operation, charge the batteries
fully. Refer to the charger operating manual.
Inserting/replacing the battery
■
Press the charged battery into the power
tool until it clicks into place (see figure B).
■
To remove, press the release button and
pull out the battery (see figure C).
CAUTION!
When the device is not in use, protect the
battery contacts. Loose metal parts may short
circuit the contacts, explosion and fire hazard!
Lanyard strap connect points
(see figure. D)
■
This tool features two lanyard connection
points. A lanyard (sold separately) reduces
the risk of dropping the tool.
WARNING
Tool is heavy! To reduce the risk of injury, do
not use wrist strap.
Install and remove the impact
socket (see figure E&F)
CAUTION!
Before carrying out any work on the power
tool, move the direction preselector switch (7)
to the middle position.
Make sure that the impact socket and the
mounting portion are not damaged before
installing the impact socket.
■
Align the square of the impact socket with the
square drive (1) and push the impact socket
onto the square drive as far as it will go.
■
Tap it lightly if required.
■
To remove the impact socket, simply pull it
off.
The square drive of 9513-2100
is equipped with a through-hole (F-1) (see
figure F). The through-hole allows for more
secure socket retention via compatible socket
and use of accessory pin and ring or one
piece retainer.
WARNING!
Do not use worn or damaged sockets.
WARNING!
The impact socket may be hot after prolonged
use. Use protective gloves when removing
the impact socket from the tool, or first allow
the impact socket to cool down.
Direction preselection
(see figure I)
CAUTION!
Change the direction of rotation only when
the power tool is stopped.
Move the direction preselector switch (7) to
the required position:
■
Position the direction preselector switch (7)
to the far left of the tool to tighten bolts/
nuts
■
Position the direction preselector switch (7)
to the far right of the tool to loosen bolts/
nuts.
■
Position the direction preselector switch (7)
in the “OFF” (center-lock) position to help
reduce the possibility of accidental starting
when not in use.
NOTE
The impact wrench will not run unless the
direction preselector switch is engaged fully
to the left or to the right.
WARNING!
Battery tools are always in operating
condition. Therefore, the direction preselector
switch should always be locked in the center
position when the tool is not in use or when
carrying it at your side.
Mode selection (see figure J)
CAUTION!
Your tool is equipped with a mode control
panel (3), located on the foot of the tool. It
consists of the drive-control button
(J-3),
the “M”
button (J-1), and LED indicators (J-
2) for working modes.
The drive-control button (J-3) is used to select
