Only use spare parts supplied by Hayward brands
®
Only use spare parts supplied by Hayward brands
®
Page 4 on 20 Page 5 on 20Control Station NG Control Station NG
Measurement
chamber +
accessories
Drilling
template
1. GENERAL
The NG Control Station is an equipment control station combined with pool water treatment regulation.
The NG Control Station can control the filtration system (pump and variable speed pump), and peripheral equipment (heat
pump, lighting, etc.). It is also an effective method for treating your pool water, using injection of liquid chlorine. The NG
Control Station is suitable for treating most residential and commercial pools. The quantity of chlorine required to treat a
pool correctly varies depending on the number of swimmers, precipitation levels, temperature and cleanliness of the water,
etc.
3. INSTALLATION
3a. Diagram of overall installation
p
H
O
R
P
H-Power
electrical
cabinet
Wi-Fi
module
Peristaltic
pump
Peristaltic
pump
Measurement
chamber
Probe-
holder
pH probe
pH probe
Rx probe
ORP probe
Flow switch
Earthing
anode
Température
probe
Heat pump
UV Module
FilterPump
Control Station NG
2. PACK CONTENTS
2a. CST-CTL-PHORPNG
2b. CST-CTL-BCNG
Chlorine
Acid
Flow
switch
Flow
switch
Box
Box
QR Code
for user
instructions
QR Code
for user
instructions
Drilling
template
Cable gland
(X2)
Cable gland
(X2)
4 rawlplugs,
4 wall mount screws,
4 eyelet hangers,
4 screws for mounting
the hangers
4 rawlplugs,
4 wall mount screws,
4 eyelet hangers,
4 screws for mounting
the hangers
pH
Probe
p
H
ORP
Probe
O
R
P
Cable gland Wi-Fi module
4 rawlplugs,
4 wall mount screws
Peristaltic pump
(1,2 / 7 L/h) (x2)
Temperature
probe
Chip
pH/rX (x2)
Saddle clamps
(x2)
Transparent mount for
probe and flow switch,
and four 1/2-inch
stoppers
Transparent mount for
probe and flow switch,
and four 1/2-inch
stoppers
