English

Safety Notes

!

Gloves should be worn during installation to prevent

crushing and cutting injuries.

!

The product may only be used for bathing, hygienic

and body cleaning purposes.

!

Children as well as adults with physical, mental and/

or sensoric impairments must not use this product

without proper supervision. Persons under the

inﬂuence of alcohol or drugs are prohibited from

using this product.

!

The hot and cold supplies must be of equal pressures.

Installation Instructions

• Prior to installation, inspect the product for transport

damages. After it has been installed, no transport or

surface damage will be honoured.

• The pipes and the ﬁxture must be installed, ﬂushed

and tested as per the applicable standards.

• The plumbing codes applicable in the respective

countries must be observed.

Technical Data

Operating pressure: max. 1 MPa

Recommended operating pressure: 0,1 - 0,5 MPa

Test pressure: 1,6 MPa

(1 MPa = 10 bar = 147 PSI)

Hot water temperature: max. 60°C

Thermal disinfection: 70°C / 4 min

• Safety against backﬂow

• The product is exclusively designed for drinking

water!

Symbol description

Do not use silicone containing acetic acid!

Safety Function (see page 67)

The desired maximum temperature for example max.

42°C can be pre-set thanks to the safety function.

Adjustment (see page 67)

After the installation, the output temperature of the

thermostat must be checked. A correction is necessary if

the temperature measured at the output diﬀers from the

temperature set on the thermostat.

Maintenance (see page 70)

• The check valves must be checked regularly accord-

ing to EN 806-5 in accordance with national or

regional regulations (at least once a year).

• To guarantee the smooth running of the thermostat, it

is necessary from time to time to turn the thermostat

from total hot to total cold.

Dimensions (see page 73)

Flow diagram (see page 73)

free ﬂow

Outlet 1

Outlet 2

Spare parts (see page 74)

XX = Colors

00 = Chrome Plated

14 = Brushed Bronze

25 = Brushed Gold-Optic

30 = Polished Redgold

34 = Brushed Black Chrome

67 = Matt Black

70 = Matt White

80 = Stainless Steel Optic

95 = Brushed Brass

99 = Gold Plated

Special accessories (see page 75)

order as an extra

• extension 25 mm #13595000

• Extension Set 22 mm (when wall is not deep

enough)#13593XX0, 13597XX0,

15597XX0

• levelling set 1° #95521000

Cleaning (see page 72)

Operation (see page 69)

Test certiﬁcate (see page 75)
