ASSEMBLY (see page 34)

FAULT CAUSE REMEDY

⁄ Insuﬃcient water ⁄ Supply pressure inadequate ⁄ Check water pressure (If a pump has been installed check

to see if the pump is working).

⁄ Regulator ﬁlter dirty ⁄ Clean ﬁlter in front of the mixer and on the MTC-thermo

cartridge

⁄ Shower ﬁlter seal dirty ⁄ Clean ﬁlter seal between shower and hose

⁄ Crossﬂow, hot water being forced into cold water pipe, or

vice versa, when mixer is closed

⁄ Backﬂow preventers dirty or leaking ⁄ Clean backﬂow preventers, exchange if necessary

⁄ Spout temperature does not correspond with temperature

set

⁄ Thermostat has not been adjusted ⁄ Adjust thermostat

⁄ Hot water temperature too low ⁄ Increase hot water temperature to 42 ºC to 65 ºC

⁄ Temperature regulation not possible ⁄ Temperature regulator dirty or calciﬁed ⁄ Clean temperature regulator, exchange if necessary

⁄ Safety stop button not operating ⁄ Spring defective ⁄ Clean spring and⁄or button, exchange if necessary

⁄ Button calciﬁed

⁄ Valve stiﬀ ⁄ Select stop valve DN9 damaged ⁄ Exchange Select stop valve DN9

⁄ Shower or spout dripping ⁄ Select stop valve DN9 damaged ⁄ Exchange Select stop valve DN9

⁄ Pushbutton cannot be actuated or is without function ⁄ Safety guard of isolating valve has not been removed ⁄ Remove safety guard from isolating valve

⁄ Pushbutton is jammed or stiﬀ ⁄ Seal needs greasing ⁄ Grease the seal

⁄ Pushbutton does not snap in ⁄ Select Adapter incorrectly trimmed ⁄ Trim and mount Select Adapter according to Fig. 6 (see

page 34)

⁄ First, fully press the pushbutton down into the rosette; then,

mount the rosette

CLEANING (see page 43)

SPARE PARTS (see page 42)

SPECIAL ACCESSORIES (see page 42 order as an extra)

INSTALLATION EXAMPLE (see page 32)

FLOW DIAGRAM (see page 31)



Outlet 1



Shower outlet

DIMENSIONS (see page 31)

OPERATION (see page 39)

Minor leaking may occur brieﬂy during initial commissioning and

interruption⁄restart of the water supply.

MAINTENANCE (see page 40)

⁄ The mixer is equipped with check valves. The check valves must be

checked regularly according to DIN EN 1717 in accordance with na-

tional or regional regulations (at least once a year).

⁄ To guarantee the smooth running of the thermostat, it is necessary from

time to time to turn the thermostat from total hot to total cold.

ADJUSTMENT (see page 38)

After the installation, the output temperature of the thermostat must be

checked. A correction is necessary if the temperature measured at the output

diﬀers from the temperature set on the thermostat.

SAFETY FUNCTION (see page 38)

The desired maximum temperature for example max. 42º C can be pre-set

thanks to the safety function.

Do not use silicone containing acetic acid!

SYMBOL DESCRIPTION



SAFETY NOTES

 Gloves should be worn during installation to prevent crushing and cutting injuries.

 The product may only be used for bathing, hygienic and body cleaning purposes.

 Children as well as adults with physical, mental and⁄or sensoric impairments must

not use this product without proper supervision. Persons under the inﬂuence of

alcohol or drugs are prohibited from using this product.

 The hot and cold supplies must be of equal pressures.

INSTALLATION INSTRUCTIONS

⁄ Prior to installation, inspect the product for transport damages. After it has been

installed, no transport or surface damage will be honoured.

⁄ The pipes and the ﬁxture must be installed, ﬂushed and tested as per the applicable

standards.

⁄ The plumbing codes applicable in the respective countries must be observed.

SPECIAL INFORMATION FOR UK

If installing this product with a pump, please be aware that it has to have negative

head switching. This product will not function with a positive head pump..

TECHNICAL DATA

Operating pressure: max. 1 MPa

Recommended operating pressure: 0,1 - 0,5 MPa

Test pressure: 1,6 MPa

(1 MPa = 10 bar = 147 PSI)

Hot water temperature: max. 70°C

Recommended hot water temp.: 65°C

Thermal disinfection: max. 70°C ⁄ 4 min

Safety against backﬂow

The product is exclusively designed for drinking water!

TEST CERTIFICATE (see page 43)
