Page EN-14 Delivery
Preparing the appliance
1. Switch the fuse off.
2. Remove cardboard, polystyrene and ad-
hesive strips from the inside, if you have
not already done so.
(29)
3. Affix the condensation protection film
supplied (29) to the underside of the work
surface. This will prevent damage to the
worktop caused by hot steam released
from inside the dishwasher when the ap-
pliance door is left open.
(31)
4. Insert the two mounting brackets (31) into
the front slots on the top of the appliance
so that you can screw the appliance to the
worktop later on.
5. Slide the appliance into the recess.
Aligning the appliance
To level the appliance, the two front adjusta-
ble feet (26) and the adjustable back foot (26)
can be adjusted by up to 50 mm.
The front adjustable feet are equipped with
slots.
You can adjust the height of the rear adjusta-
ble foot with the centre adjusting screw (34).
(34)
(26)
1. Insert a crosshead screwdriver into one of
the slots and turn the adjustable feet (26)
to the height required.
2. Check the alignment with a spirit level.
3. Make sure that the top edge of the ap-
pliance is up to the bottom edge of the
worktop to prevent it from tipping forward
when the appliance door is opened.
