Page EN-13
Delivery
tective contact socket with sufficient fuse
protection (220 – 240 V~/50 Hz/10 A).
• Ensure that the plug is installed in such a
way that the recess into which the dish-
washer will be fitted is deep enough even
when the plug is plugged in.
• Do not use a multi-socket extension ca-
ble, multi-socket plug, travel adapter, ex-
tension cable or similar.
We recommend using a pulse-sensitive
residual current device (RCD).
• Insert the mains plug into the socket.
Installing the appliance under
a worktop
NOTICE
Risk of damage to property!
Selecting the wrong screws can dam
-
age the worktop.
■ Use the screws which are supplied in
the delivery or screws of an appropri
-
ate length.
• Only install the dishwasher underneath a
continuous worktop which is joined to the
units adjacent to the dishwasher.
• Maintain sufficient distance from the walls
and adjacent appliances. The measure-
ments of the recess must at least corre-
spond to the details in the diagram above.
90°
600 mm
820-870 mm
100 mm
580 mm
80 mm
90°
(Feet adjustable)
Inlet/outlet area
and electrical con-
nection.
Recess
dimensions
