4 49-5001070 Rev. 0
ENGLISH
Remote Control
1. POWER Button
Press the ON/OFF button on the remote control to start or
stop the unit.
2. Cool Button
In Cool mode, the unit operates in cooling. When Fan is
set to Auto, the heat pump automatically adjusts the fan
speed according to the room temperature. The will be
displayed during COOL mode.
3. Heat Button
In Heat mode, warm air will blow out after a short period
of time due to the cold-air prevention function. When Fan
is set to Auto mode, the heat pump automatically adjusts
the fan speed according to room temperature. The will
be displayed during Heat mode.
4. Temp +/- Button
Temp + : Every time the button is pressed, the temperature
setting increases.
Temp – : Every time the button is pressed, the temperature
setting decreases. The operating temperaturerange is
60°F-86°F (16°C-30°C).
5. Fan Speed Button
Fan Speed: For each press the fan speed changes as
follows:
Remote control:
AUTO
HI
MED LOW
(Display
circulated)
Quiet
Turbo
6. Dry Button
Dry mode is used to reduce humidity. In Dry mode, when
room temperature becomes lower than temperature
setting +2°F, unit will run intermittently at Low speed
regardless of Fan setting. The will be displayed during
Dry mode.
7. Fan Mode Button
Fan mode circulates air only; there is no temperature
adjustment available. Use the fan speed button (5) to adjust
fan speed from low, medium to high. In this mode, Auto,
Turbo and Quiet are not available.
8. Turbo Button
The Turbo function is used for fastest air flow in Heating or
Cooling modes. Controls display the Turbo icon on the
bottom right side of the remote display. Pressing the Turbo
again or Fan Speed button will turn Turbo off.
9. Quiet Button
The Quiet function switches the fan to the lowest speed.
The control will display the Quiet icon on the bottom
left side of the remote display. Pressing the Quiet button
again or the Fan Speed button will turn Quiet off.
10. Louver UP/DOWN Button
Press the Louver UP/DOWN button to choose the
position of the horizontal airflow louvers.
Status display of airflow.
Cool/Dry:
Heat:
NOTE:
a. It is advisable not to keep the vertical louver in the
downward position for an extended period of time in
Cool or Dry mode,otherwise condensate water may
form on the louver.
b. When turning the unit on, the remote control will
automatically return the louver to the previous set
swing position. When turning the unit off, the louver will
rotate to the full open position prior to closing.
REMOTE CONTROL FEATURES AND SETTINGS
