US09CB2BEA US12CB2BEA US18CB2BEA US24LB2BEA
Panel Model QACCP01WA QACCP01WA QACCP01WA QALCP01WA
Rated Capacity Btu/hr 9,000 12,000 18,000 24,000
Voltage, Cycle, Phase V/Hz/Phase 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Fan Speed Stages 5 + Auto 5 + Auto 5 + Auto 5 + Auto
Motor Speed RPM: Cooling
(Turbo/High/Med/Low/Quiet)
830/760/690/620/560 830/760/690/620/560 850/800/760/680/590 620/580/540/430/360
Motor Speed RPM: Heating
(Turbo/High/Med/Low/Quiet)
830/760/690/620/560 830/760/690/620/560 850/800/760/680/590 620/580/540/430/360
Airow CFM: Cooling
(Turbo/High/Med/Low/Quiet)
440/387/351/320/290 440/387/351/320/290 458/425/387/345/302 1033/873/858/640/400
Airow CFM: Heating
(Turbo/High/Med/Low/Quiet)
440/387/351/320/290 440/387/351/320/290 479/441/387/345/302 1033/873/858/640/400
Indoor Sound Level dB: Cooling
(Turbo/High/Med/Low/Quiet)
42/40/36/32/25 45/42/40/36/32 45/42/40/36/32 46/44/41/38/35
Indoor Sound Level dB: Heating
(Turbo/High/Med/Low/Quiet)
42/40/36/32/25 45/42/40/36/32 45/42/40/36/32 46/44/42/39/36
Chassis Dimension: HxWxD in (mm)
10 1/4 x 22 3/4 x 22 3/4
(260 x 575 x 575)
10 1/4 x 22 3/4 x 22 3/4
(260 x 575 x 575)
10 1/4 x 22 3/4 x 22 3/4
(260 x 575 x 575)
9 3/4 x 33 x 33
(248 x 840 x 840)
Panel Dimension: HxWxD in (mm)
2 3/8 x 27 7/16 x 27 7/16
(60 x 620 x 620)
2 3/8 x 27 7/16 x 27 7/16
(60 x 620 x 620)
2 3/8 x 27 7/16 x 27 7/16
(60 x 620 x 620)
1 15/16 x 37 3/8 x 37 3/8
(50 x 950 x 950)
Weight (Net/Ship)- lbs (kg) 32.41/47.4 (14.7/21.5) 32.41/47.4 (14.7/21.5) 32.41/47.4 (14.7/21.5) 56.22/85.32 (25.5/38.7)
Liquid Pipe O.D. (in) 1/4 1/4 1/4 3/8
Suction Pipe O.D. (in) 3/8 3/8 1/2 5/8
Drainpipe Size O.D. (in) 1* 1* 1* 1*
Condensate Pump Built-In Yes Yes Yes Yes
Max. Drain-Lift Height in (mm) 47 1/4 (1200) 47 1/4 (1200) 47 1/4 (1200) 47 1/4 (1200)
WiFi**
Built-in Built-in Built-in Built-in
Factory-Installed Refrigerant Detection
Sensor (RDS)
No No No No
Refrigerant Detection Sensor (RDS)
Compatible
Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately)
CASSETTE
COMPACT DESIGN
Fits 2’ x 2’ drop ceiling for easy installation.
CONDENSATE PUMP
Factory-installed condensate pump.
FRESH AIR KNOCKOUT
Unit designed with a 4” round fresh air knockout.
WARM START
Ensures the fan does not blow cold air during heating mode
startup.
TURBO MODE
Delivers rapid cooling or heating, making it ideal for quickly
adjusting the room temperature.
INDEPENDENT LOUVER CONTROL
The four cassette louvers can be set to the same, or
dierent positions, to control airow direction.
*Condensate drain adapter shipped with the indoor unit is designed to accept a 3/4” PVC pipe. **WiFi includes SmartHQ
TM
Home and SmartHQ
TM
Service compatibility.
Multi-Zone
Indoor Unit Specications
