QS09WP2BEA QS12WP2BEA QS18WP2BEA QS24WP2BEA
Rated Capacity Btu/hr 9,000 12,000 18,000 24,000
Voltage, Cycle, Phase V/Hz/Phase 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Fan Speed Stages 5 + Auto 5 + Auto 5 + Auto 5 + Auto
Motor Speed RPM: Cooling
(Turbo/High/Med/Low/Quiet)
1200/1100/875/650/610 1300/1250/1050/850/610 1300/1250/1050/850/800 1300/1200/1050/900/750
Motor Speed RPM: Heating
(Turbo/High/Med/Low/Quiet)
1200/1100/900/700/610 1300/1250/1150/1050/610 1300/1250/1025/800/750 1300/1200/1050/900/750
Airow CFM: Cooling
(Turbo/High/Med/Low/Quiet)
395/355/310/260/170 410/370/280/210/170 580/530/480/400/350 800/730/630/535/440
Airow CFM: Heating
(Turbo/High/Med/Low/Quiet)
395/355/290/220/170 420/390/350/310/180 580/530/450/350/320 800/730/630/535/440
Indoor Sound Level dB: Cooling
(Turbo/High/Med/Low/Quiet)
44/42/36/32/27 46/44/38/32/25 51/50/44/37/25 54/50/47/44/38
Indoor Sound Level dB: Heating
(Turbo/High/Med/Low/Quiet)
43/41/37/32/29 43/42/39/36/25 49/47/40/35/26 54/50/47/44/38
Auto Up-Down Louver Yes Yes Yes Yes
Auto Left-Right Louver Yes Yes Yes Yes
Dimension: H x W x D in (mm)
12 1/4 x 36 x 8 3/8
(312 x 914 x 213)
12 1/4 x 36 x 8 3/8
(312 x 914 x 213)
12 7/8 x 39 3/4 x 8 3/4
(327 x 1009 x 223)
13 1/2 x 44 1/2 x 9 1/8
(343 x 1129 x 232)
Weight (Net/Ship)- lbs (kg) 24.49/30.56 (11.1/13.85) 24.49/30.56 (11.1/13.85) 29.57/36.63 (13.4/16.6) 34.86/43.03 (15.8/19.5)
Liquid O.D. in 1/4 1/4 1/4 1/4
Suction O.D. in 3/8 3/8 1/2 1/2
Drain Pipe Size O.D in 5/8 5/8 5/8 5/8
WiFi*
Built-in Built-in Built-in Built-in
Factory-Installed Refrigerant Detection
Sensor (RDS)
No No No No
Refrigerant Detection Sensor (RDS)
Compatible
Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately) Yes (UALS01A, sold seperately)
PREMIUM HIGHWALL
WARM START
Ensures the fan does not blow cold air during heating
mode startup.
TURBO MODE
Delivers rapid cooling or heating, making it ideal for
quickly adjusting the room temperature.
INDOOR AIR FILTER
The easily removable and cleanable indoor air lter
reduces maintenance time, ensuring cleaner air and
longer-lasting eciency.
3-D AIRFLOW
Designed to oscillate up and down, left and right
automatically, ensuring optimal distribution of
conditioned air throughout the space.
SMART SENSOR
Automatically changes to an energy-saving temperature
while you are away, then back to your regular setting when
you return.
FOLLOW & SURROUND
Allows the user to choose if the air is directed towards
them (follow) or away from them (surround).
EXTENDED KICKSTAND
The built-in bracket provides extra room for easier
installation and service.
MOUNTING TEMPLATE/PLATE
A convenient printed cardboard template and mounting
plate enable accurate, single-person installation, ensuring
correct positioning of the lineset and drain opening.
2-WAY PIPING DRAIN
Flexible right or left side condensation drain options
simplify installation (right side only with RDS installed).
EASY-ACCESS PCB
The PCB pops out for quick component and wiring checks,
eliminating the need to remove the casing.
*WiFi includes SmartHQ
TM
Home and SmartHQ
TM
Service compatibility.
Multi-Zone
Indoor Unit Specications
