24 31-5001082 Rev. 2
ENGLISH
INSTALLATION INSTRUCTIONS
LOW AMBIENT INSTALL
- If the outdoor unit is installed in a region that is affected by strong wind or snow accumulation, it is recommended to
install wind baffle or/and top cover accessories. Corresponding top cover and wind baffle model number can be found
in product catalog. The installation instructions can be found in the manual shipped with each accessory or on-line at
GEAppliancesairandwater.com.
SALTWATER COAST INSTALL
• The outdoor unit should be installed at least ½ mile away from the salt water, including seacoasts and inland
waterways. If the unit installed from ½ mile to 5 miles away from the salt water, including seacoasts and inland
waterways, please follow the installation instruction below.
• Install the outdoor unit in a place (such as near buildings etc.) where it can be protected from sea breeze which can
damage the outdoor unit.
• If you cannot avoid installing the outdoor unit by the seashore, construct a
protection wall around it to block the sea breeze.
• A protection wall should be constructed with a solid material to block the sea
breeze. The height and the width of the wall should be 1.5 times larger than
the size of the outdoor unit. Also, allow at least 28“ (700mm) between the
protection wall and the outdoor unit for air circulation to ventilate.
• Install the outdoor unit in a place where water can drain freely.
• If the above conditions cannot be met, contact GE Appliances for assistance.
Protection Walls
Sea Breeze
Sea
ODU
ODU
Sea Breeze
Sea
ODU
Sea Breeze
Sea
ODU
ODU
