TROUBLESHOOTING & REFERENCES
Ï¡(
ENGLISH
ÎõõòõÌòçè ¤Òñçòòõ¦Øø÷çòòõ¥
Ï(¦ÕÎÍ!)Ïïäöë
Outdoor DC Fan Motor Fault
Complete the “Check This First” Flow Chart
before continuing.
Öòçèïö
AW24TL2HFA
AW30TL2HFA
AW36TL2HFA
No
Yes
Yes
Yes
Yes
NoYes
No
Yes
No
Êççúìñçåäħè¦
protection from wind.
Fix incoming power supply
Replace the fan motor
Replace the
fan motor.
Replace the
main board.
Start
Check the incoming voltage.
Is it 208/230VAC (+/- 10%) between L1/L2?
104/115VAC (+/- 10%) from L1 to GROUND and L2 to GROUND?
àì÷ë÷ëèóòúèõòģ÷øõñ÷ëèéäñåüëäñç
Does it move / rotate smoothly?
Re-apply power. Does the
fan come on and spin?
Measure DC voltage at fan motor plug
CN21 between the Pin 6 (BLUE) and Pin 3
(BLACK) wire while spinning the fan motor.
Does it generate 2~9VDC?
No
No
No
Replace the
main board.
Replace the
main board.
Replace the
main board.
Measure DC voltage at fan motor plug CN21
between Pin 1 (RED) and Pin 3 (BLACK).
Does it measure 300~380VDC (+/-10%)?
Measure DC voltage at fan motor plug CN21
between Pin 4 (WHITE) and Pin 3 (BLACK).
Does it measure between 13.5-16.5VDC?
Measure DC voltage at fan motor plug CN21
between Pin 5 (YELLOW) and Pin 3 (BLACK).
Does it measure between 2-6VDC?
Not Windy Windy
Yes
Before going to the next step, is the
unit in an area susceptible to high
winds? High winds blowing into the
fan may cause added resistance
and subsequently lower fan speeds
enough to cause the unit to fault. If
this is the case the unit only faults
çøõìñêúìñçüöì÷øä÷ìòñöäúìñçåäħè
may need to be added.
ÝÛØÞËÕÎÜÑØØÝÒ×ÐÏÕØàÌÑÊÛÝÜ
31-5000936-1
