12 31-5001078 Rev. 0
ENGLISH
INSTALLATION INSTRUCTIONS
Required Tools for Installation
• 5/8” (16mm), 7/8” (22mm), 1” (25mm) or adjustable
wrench
• Adhesive tape
• Conduit cable clamp ½”*
• ACR Copper line set
(refer to outdoor installation manual
for line set size)
• #2 phillips screwdriver
• Drill
• R454B flaring tool
• Hex wrench
• Hole saw 2 ¼”
• Refrigerant scale
• Level
• Manifold gauge set
• Measuring tape
• Micron gauge
• Mini-split adapter (W\IN” F to ¼” M)
• Nitrogen*
• Pipe cutter
• Razor knife
• Reamer
• Saddle clamp (L.S.) w/ screws
• Sealant, non-expanding (for lineset hole)
• Soap/water solution* or gas leakage detector
• Stud finder
• Torque wrench
• Vacuum pump
• Wire strippers
• All usual and customary HVAC hand and power tools,
meters, and testing devices
• Valve core removal tool
• Fire extinguisher or dry powder
– * consumable
Operating Environment
NOTE: This air conditioner is designed to be operated under condition as follows and performance may be reduced
outside of these operating temperatures.
Note:
To achieve optimal capacity and efficiency at 5°F (-15°C) and below, it is recommended to operate the indoor unit fan at
the highest setting (Turbo Mode for some models).
Operating Range
Cooling
Tempo 115V
23°F~115°F(-5°C~46°C)Arctic
FlexFit
Tempo 230V 14°F~115°F(-10°C~46°C)
Heating
Tempo 115V
-4°F~75°F(-20°C~24°C)
Tempo 230V
FlexFit -15°F~75°F(-26°C~24°C)
Arctic -31°F~75°F(-35°C~24°C)
Supplied by Installer
Refrigerant Line Set: for sizing please refer to the Outdoor Unit Rating Plate
• 14/4 AWG SOOW Non-Shielded Stranded Copper Cable
• R454B Refrigerant (if extra charge is needed, see next section)
• Refrigerant Line Insulation (follow local code requirements)
• PVC Pipe (optional)
• Condensate Drain Tubing Clamp
• 16/2 AWG Shielded SOOW Cable for high speed communication
• Hardware to secure ODU feet to platform
– Suggestion: M10*30 (bolt diameter is M10; bolt length is 30 mm)”
NOTE: Disconnect, panel breaker, supply cable for connecting wires from the disconnect to the ODU.
