Je bekijkt pagina 90 van 308
88
Technical changes reserved
tehalit.BKB
electraplan.BK
Order number system
Identifier Type Trunking width
Nominal size
Levelling range
BK = floor trunking X
F = with foil
W = with trunking bottom
FD = with foil and sealing option
WD = with trunking bottom and sealing option
Y
150
200
250
300
350
400
500
600
Z
(foil)
045 = 45 - 70 mm
065 = 65 - 110 mm
105 = 105 - 150 mm
145 = 145 - 190 mm
(trunking bottom)
040 = 40 - 60 mm
050 = 50 - 70 mm
060 = 60 - 100 mm
070 = 70 - 110 mm
080 = 80 - 120 mm
090 = 90 - 130 mm
Identifier Type with sealing
option
Trunking width
Nominal size
Type of blanking
BK = floor trunking W
A = cover
X
= standard (without
sealing tape)
D = for sealing tape
Y
150
200
250
300
350
400
500
600
Z
= without blanking
GBZ = blanking GBZ round 50 mm
R06 = blanking R06 round 215 mm
R10 = blanking R10 round 275 mm
R12 = blanking R12 round 306 mm
Q06 = blanking Q06 200 x 200 mm
Q08 = blanking Q08 294 x 294 mm
Q12 = blanking Q12 244 x 244 mm
E04 = blanking E04 147 x 247 mm
E09 = blanking E09 200 x 253 mm
Floor trunking
Floor trunking sealing end piece
Floor trunking covers
Identifier Type with sealing
option
Trunking width
Nominal size
BK = floor trunking X
T = cross member
TM = cross member with
centre support
Y
N = standard (without
sealing strip)
D = for sealing tape
Z
150
200
250
300
350
400
500
600
Floor trunking cross members
Identifier Type Type Trunking width
Nominal size
Levelling range
BK = floor trunking W
F = with foil
W = with trunking bottom
FD = with foil and
sealing option
WD = with trunking bottom
and sealing option
X
V = sealing piece
E = end piece
Y
150
200
250
300
350
400
500
600
Z
(trunking bottom)
040 = 40 - 60 mm
050 = 50 - 70 mm
060 = 60 - 100 mm
070 = 70 - 110 mm
080 = 80 - 120 mm
090 = 90 - 130 mm
