83
Technical changes reserved
tehalit.BKB
tehalit.BKB
Installation instructions
tehalit.BKB is designed for installation along walls or window fronts
for screed-flush floor installations. Installation with a closed upper
part is also possible within a room. The trunking system comes with
an upper part with a closed design, a brush and an LED chamber
with brush.
Product features
• Suitable for dry-cleaned floors in accordance with DIN EN 50085
• Suitable for floor coverings with a thickness ranging from
5 to 25 mm
• The upper part can be covered with dry-cleaned floor coverings
(carpet, parquet flooring, laminate,…) or with wet-cleaned floor
coverings (natural stone, marble, tiles,…). Due to the open design,
the trunking system is only suitable for dry-cleaned rooms.
• Floor covering is glued onto the cover
• Recommended minimum height of trunking = minimum screed
height = 96 mm
• Do not forget the edge insulation strip between the trunking and
the screed!
• It may be necessary to install sound insulation at the transition be-
tween office units (sound insulation barrier, product no. L5804, see
catalogue ‘Leitungsführung + Raumanschlusssysteme’)
• A trunking firewall (BS90SET) must be installed when routing the
trunking through fire safety walls
• Other trunking heights and widths available on request
• Height levelling via internally accessible adjustment screws
• Easy access to cables and sockets is provided via the removable
upper part and via the cable outlet on the wall side on upper parts
with a brush. Length of the upper parts: 1 m, length of the trunking
bottom part: 2 m.
• Also available as closed trunking without a cable outlet for installa-
tion in areas that people walk in
• Withstands point loads of up to 150 kg (in accordance with the
relevant standard)
• Separate delivery of the lower part (always with fitting frame) and
3 different upper parts (with brush, closed, with brush and LED
compartment)
Advantages
• Investors can split investment requirements into separate construc-
tion and building equipment management phases .
• Users benefit from great application and upgrade flexibility with an
almost invisible energy and data network infrastructure
• Simplified planning process through integration of group connec-
tion points or device installation
• Separate delivery of upper and lower parts – allowing basic instal-
lation in the preliminary building works phase and completion in the
final construction phase
• Suitable upper parts can be used freely to match the final place-
ment of furniture.
• Upper and lower parts are delivered separately, but the lower part
is always supplied with a fitting frame to prevent the risk of per-
sonal injury during preliminary building works.
• Installation depends on the way the office space is divided up and
used.
• Easy options for changing the energy and data network infrastruc-
ture once the system is in use.
• Removable covers offer access to the installation space.
• Can be combined with Hager system components
• Also suitable for use in the home for energy, media and data con-
nection systems+
Device installation
• Group connection points for energy and data network
• All products from the installation device range, e. g.
- Energy distribution
- Sockets
- Overvoltage protection
- Network connections
- Antenna sockets
- Also suitable for installation of Electraplan devices
Line occupancy (guide values)
• Compartment 1: 31 x ø11 mm; e. g. 3 x 1.5 mm²
• Compartment 2: 25 x ø11 mm; e. g. 3 x 1.5 mm²
Installation concept
Preliminary building works phase
1. Installation of the tehalit.BKB system along outer walls or glass
fronts in the screed flooring. If possible, a direct connection should
be made between the tehalit.BKB system and the cable distribu-
tion room or the sub-distribution.
2. Basic installation of the energy and data network infrastructure
in the tehalit.BKB system via group connection points. The dis-
tribution and number of group connection points depends on the
required volume of equipment in the office space (at least 1 group
connection point for every 20 to 40 m²).
3. Ensure the installation is compliant with the following standards
by using group connection points or conventional connections:
- Energy distribution systems: DIN VDE 0634 Part 1 and Part 2, DIN
VDE 0100 (in particular Part 520), DIN VDE 0105,
- Data network systems: Structured cabling in accordance with EN
50173-1, EN 50173-4, EN 50174-2
Final construction phase
1. Individual installation only once the room layout and usage have
been defined
2. Connection of consumers close to walls directly via the group
connection points (no additional installation components required)
3. Connection of consumers out in the open using additional Hager
system components
4. Pluggable connection systems for safe and reliable installations
Usage phase
5. Flexible and quick changes can be made to the energy and data
cabling if the room layout or usage change.
6. Optional installation of plinths
