184
Technical changes reserved
electraplan.VE-EE
electraplan.VE-EE
Order number system
Service units - Installation units
Identifier Shape/number of installation
devices
Flooring cutout
/cover inlay - cardboard
Colour/material
V = service unit
VE = Service unit made of
stainless steel
VD = Cover
VEDE = service unit cover
inlay
VDDE = cover inlay
Y
R06 = round 215 mm
R10 = round 275 mm
R12 = round 306 mm
Q06 = square 200 x 200 mm
Q12 = square 244 x 244 mm
E09 = square 200 x 253 mm
Y
05 = 5 mm flooring cutout
12 = 12 mm flooring cutout
P1 = cover inlay with 1 mm material
thickness
P2 = cover inlay with 2 mm material
thickness
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
E = stainless steel
Service units - installation units - heavy-duty stainless-steel cassettes
Service units - installation units - stainless-steel cassettes - heavy-duty - accessories - levelling set
Identifier
Material
Shape/number of installation
devices
Max. Load-bearing capacity Variant
EKS = heavy-duty stain-
less-steel cassette
X
R06 = round 215 mm
R12 = round 306 mm
Q405 = square 405 x 405 mm
Q06 = square 200 x 200 mm
Q12 = square 244 x 244 mm
Y
20 = 20 kN
Z
BL = blank
TM = tube mounting set
Identifier Type Levelling range
EKS = heavy-duty stain-
less-steel cassette
Y
NS = levelling set
Z
075 = 100 - 150 mm
120 = 145 - 195 mm
165 = 190 - 240 mm
Service units - installation units - height-adjustable stainless-steel cassettes
Identifier
Material
Shape/number of installation
devices
Variant Cassette height
EK = stainless-steel cassette
X
R06 = round 215 mm
R12 = round 306 mm
Q06 = square 200 x 200 mm
Q12 = square 244 x 244 mm
Y
00BL = blank
00TM = tube mounting set
00LE = cable outlet, square
Z
1 = 23 mm inside - 28 mm outside
2 = 38 mm inside - 43 mm outside
Service units - installation units, height-adjustable stainless-steel cassettes - accessories - tube cable outlets
Service units - installation units, height-adjustable stainless-steel cassettes - accessories - levelling set
Identifier Type Levelling range
EK = stainless-steel cassette Y
NS = levelling set
Z
075 = 100 - 150 mm
120 = 145 - 195 mm
165 = 190 - 240 mm
Identifier Type Material Outer diameter
TU = tube X
LA = cable outlet
SS000 = pin wrench
Y
A = aluminium
Z
105 = 105 mm
