85
Technical changes reserved
tehalit.BKB
tehalit.BKB
Installation sequence for the trunking system
11. All metallic parts of the trunking system must be covered by VDE-compliant protection measures.
12. Application of the floor covering (0-25 mm).
13. Floor covering adjustment – version 1 with brush:
The outlet brush supplied with the upper part is attached to the wall side of the trunking lower part
and adjusted in the same way as the floor covering stop attached to the trunking lower part to the
corresponding height of the floor covering by pushing it upward or downward, after which it is then
tightened in place using a 3-mm Allen key (not included in the delivery package).
14. Floor covering adjustment – version 2 closed:
The floor covering stop supplied with the upper part and the support for the upper part are attached
to the wall side of the trunking lower part and adjusted in the same way as the floor covering stop
attached to the trunking lower part to the corresponding height of the floor covering by pushing them
upward or downward, after which they are then tightened in place using a 3-mm Allen key (not in-
cluded in the delivery package).s Note: the “support rake” (system carrier) in the lower part needs to
be moved to allow the upper part to fit.
15. Floor covering adjustment – version 2 with LED:
The outlet brush supplied with the upper part is attached to the wall side of the trunking lower part
and adjusted in the same way as the floor covering stop attached to the trunking lower part to the
corresponding height of the floor covering by pushing it upward or downward, after which it is then
tightened in place using a 3-mm Allen key (not included in the delivery package).
Note: the “support rake” (system carrier) in the lower part needs to be moved to allow the upper part
to fit correctly.
Advantages of the tehalit.BKB system
The balustrade floor trunking offers many advantages in day-to-day use: even in areas without walls, con-
nections can be made available wherever they are required. The installation is concealed and therefore
has no impact on the overall appearance of the office space. Excess connecting cable lengths or data
network components can be easily hidden in the trunking, so there are no loose lines that get in the way in
the room.
If you decide to change the way the office space is used at a later date, this is no problem thanks to
the removable covers of the tehalit.BKB system, which offer easy access to lines, devices and group
collection points. Retrofit installations are thus possible at any time. The selection of upper parts can be
adapted at any time to meet the changing requirements of tenants or owners.
