89
Technical changes reserved
tehalit.BKB
electraplan.BK
Order number system
Identifier Type Type of blanking
BK = floor trunking Y
SA = side junction box
Z
B00 = without blanking
G00 = blanking GBZ round 50 mm
R06 = blanking R06 round 215 mm
R10 = blanking R10 round 275 mm
R12 = blanking R12 round 306 mm
Q06 = blanking Q06 200 x 200 mm
Q08 = blanking Q08 294 x 294 mm
Q12 = blanking Q12 244 x 244 mm
E04 = blanking E04 147 x 247 mm
E09 = blanking E09 200 x 253 mm
Identifier Type Material Nominal height
BK = floor trunking X
TW = partition wall
Y
K = plastic
- PS
F00 = plastic foot
S = steel panel
Z
(plastic)
16 = 16 mm – for trunking height 30 mm
31 = 31 mm – for trunking height 45 mm
46 = 46 mm – for trunking height 60 mm
61 = 61 mm – for trunking height 75mm
76 = 76 mm – for trunking height 90 - 100 mm
91 = 91 mm – for trunking height 105 - 120 mm
(sheet metal)
20 = 20 mm – for trunking height 45 mm
35 = 35 mm – for trunking height 60 mm
50 = 50 mm – for trunking height 75 mm
65 = 65 mm – for trunking height 90 mm
80 = 80 mm – for trunking height 100 mm
95 = 95 mm – for trunking height 105 mm
110 = 110 mm – for trunking height 120 mm
Floor trunking junction boxes
Floor trunking junction boxes – levelling set
Floor trunking partition walls
Identifier Type Addition Levelling range
BK = floor trunking X
SA = side
Junction box
Y
N = levelling set
Z
045070 = 45 - 70 mm
065110 = 65 - 110 mm
105150 = 105 - 150 mm
145190 = 145 - 190 mm
Identifier Type Type Colour/angle/height/length
BK = floor trunking X
Z = accessories
Y
SA = earth connection
SAK00 = earth conductor clamp
M = sponge rubber strips
BSK = abutting edge for covering
BSA = butt joint cover
EA00 = screed anchor
VS = connection set
KV = trunking connector
N = levelling clamp
NS = set screw
KM = lock nut
HP00 = retaining tab
NSD0 = soundproofing mount for set screws
SH = suction lifter
KH = claw lifter
Z
200 = length 200 mm
203 = 20 x 3 mm
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
7011 = RAL 7011, iron grey
90 = angled, 90 degrees
180 = straight, 180 degrees
090 = angled, 90 degrees
030 = from trunking height 30
050 = from trunking height 50
25 - 160 = levelling height
80 = for M8
20 = load-bearing capacity up to 20 kg
30 = load-bearing capacity up to 30 kg
30 = load-bearing capacity up to 30 kg
Floor trunking accessories
