117Technical changes reserved
electraplan.AK
On-the-floor
trunking
Note
- Screws, dowels and other materials for installing the on-the-floor trunking system
are not included in the scope of delivery.
- Holes are not countersunk.
- Countersinking of attachment holes for individual configurations with flooring,
available on request
- The term upper part extended 100 mm means 100 mm width overhang.
The cover is used, for example, for heating pipes laid in the floor area.
Blank cover
Length 800 mm
Steel sheet
AKB81500702
PU 1 pc
AKB82000702
PU 1 pc
AKB82500702
PU 1 pc
AKB83000702
PU 1 pc
AKB83500702
PU 1 pc
AKB84000702
PU 1 pc
Blank cover
Length 400 mm
Steel sheet
AKB41500702
PU 1 pc
AKB42000702
PU 1 pc
AKB42500702
PU 1 pc
AKB43000702
PU 1 pc
AKB43500702
PU 1 pc
AKB44000702
PU 1 pc
Blank cover
800 mm -
extended 100
Steel sheet
AKB81500701V
PU 1 pc
AKB82000701V
PU 1 pc
AKB82500701V
PU 1 pc
AKB83000701V
PU 1 pc
AKB83500701V
PU 1 pc
AKB84000701V
PU 1 pc
Outer corner
Extended 100 mm
Steel sheet
AKBA1500701V
PU 1 pc
AKBA2000701V
PU 1 pc
AKBA2500701V
PU 1 pc
AKBA3000701V
PU 1 pc
AKBA3500701V
PU 1 pc
AKBA4000701V
PU 1 pc
Blank cover
400 mm -
extended 100
Steel sheet
AKB41500701V
PU 1 pc
AKB42000701V
PU 1 pc
AKB42500701V
PU 1 pc
AKB43000701V
PU 1 pc
AKB43500701V
PU 1 pc
AKB44000701V
PU 1 pc
Inner corner
Extended 100 mm
Steel sheet
AKBI1500701V
PU 1 pc
AKBI2000701V
PU 1 pc
AKBI2500701V
PU 1 pc
AKBI3000701V
PU 1 pc
AKBI3500701V
PU 1 pc
AKBI4000701V
PU 1 pc
End piece
Steel sheet
AKE1500702
PU 1 pc
AKE2000702
PU 1 pc
AKE2500702
PU 1 pc
AKE3000702
PU 1 pc
AKE3500702
PU 1 pc
AKE4000702
PU 1 pc
45°Abzweig
Length 800 mm
Steel sheet
AKBAZ1500702
PU 1 pc
AKBAZ2000702
PU 1 pc
AKBAZ2500702
PU 1 pc
AKBAZ3000702
PU 1 pc
AKBAZ3500702
PU 1 pc
AKBAZ4000702
PU 1 pc
