Je bekijkt pagina 153 van 157
APPENDIX
153
Setting
Accuracy
±100 mV
Operation
Turns the output off, displays OVP
OCP
Setting
range
0.15 A - 3.3 A(GPP-1323)
0.25 A - 5.5 A(GPP-1205)
Setting
Accuracy
±20 mA
Operation
Turns the output off, displays OCP
OTP
Operation
Turns the output off, displays OTP
Trigger
Signal*1
Trigger
Input
A high or low level CMOS signal is applied
for 100 us or longer.
It receives a pulse to perform actions like
power output, V/I set operation or
memory recall.
Trigger
Output
Trigger output: approx. 3.3 V Pulse width:
approx. 1ms, Output impedance: approx.
50 Ω
It outputs a pulse when power output, V/I
set operation or memory recall is executed.
Status
Signal
Out*1*2
OUT
ON/OFF
STATUS
Turns on when the output is on
CV STATUS
Turns on during CV operation
CC STATUS
Turns on during CC operation
ALM
STATUS
Turns on when an alarm has been
activated
PWR ON
STATUS
Turns on when the power is turned on
Interface
Capabilitie
s
LAN
MAC Address, Gateway IP Address,
Instrument IP Address, Subnet Mask
USB
Type A: Host, Type B: Slave, Speed:
1.1/2.0, USB-CDC/TMC
GPIB
(Factory
Optional)
SCPI-1993, IEEE 488.2 compliant interface
Series and
Parallel
Capability
Parallel
number
4 units
Series
number
4 units
