GPE-1326A/2323A/3323A/4323A Series User Manual
48
Display
LCD
4.3-inch single color LCD display
Ammeter
CH1/CH2: 3.200 A full scale, 4 digits 或 3 digits
CH3: 1.000 A full scale，4 digits 或 3 digits
CH4: 1.000 A full scale，4 digits 或 3 digits
6.200 A full scale, 4 digits 或 3digits (GPE-1326A)
Current
Resolution
1 mA or 10 mA
2 mA or 10 mA (GPE-1326A)
Voltmeter
CH1/CH2: 32.00 V full scale,4 digits 或 3digits
CH3: 5.00 V full scale,4 digits 或 3 digits
CH4: 15.00 V full scale,4 digits 或 3 digits
Voltage
Resolution
10 mV or 100 mV
Accuracy
Setting/
Read back
Accuracy
Voltage: ± (0.1 % of reading + 30 mV) (4digits)
± (0.1 % of reading + 200 mV) (3digits)
Current: ± (0.3 % of reading + 6 mA) (4digits)
± (0.3 % of reading + 20 mA) (3digits)
(1326A) ± (0.3 % of reading + 10 mA) (4digits)
(1326A) ± (0.3 % of reading + 20mA) (3digits)
CH3 on the
GPE-3323A
Output
5 V ± 5 %, 5 A
Line
≤ 3 mV
Load
≤ 5 mV
Ripple & Noise
≤ 1 mVrms (5 Hz to 1 MHz)
OVP
5.5 V
Insulation
Chassis and Terminal
20 MΩ or above (DC 500 V)
Chassis and AC cord
30 MΩ or above (DC 500 V)
Operation
Environment
Indoor use, Altitude: ≤ 2000 m
Ambient temperature: 0 °C to 40 °C
Relative humidity: ≤ 80 %
Installation category: II; Pollution degree: 2
Storage
Environment
Ambient temperature: -10 °C to 70 °C
Relative humidity: ≤ 70 %
Power Source
AC 100 V / 120 V / 220 V ± 10 %, 230 V + 10 %/-6 %,
50/60Hz
Consumption
550 VA / 420 W, MAX
