APPENDIX
47
Specifications
The specifications apply when the GPE-1326A/2323A/3323A/
4323A series are powered on for at least 30 minutes under +20 °C to
+30 °C.
Output Ratings
CH1/CH2
Independent
0 V to 32 V / 0 A to 3 A
0 V to 32 V / 0 A to 6 A (GPE-1326A)
CH1/CH2 Series
0 V to 64 V / 0 A to 3 A
CH1/CH2 Parallel
0 V to 32 V / 0 A to 6 A
CH3
5 V, 5 A (GPE-3323A)
0 V to 5 V, 1 A (GPE-4323A)
CH4
0 V to 15 V, 1 A
Voltage
Regulation
Line
≤ 0.01 % + 3 mV
Load
≤ 0.01 % + 3 mV (rating current ≤ 3 A)
≤ 0.02 % + 5 mV (rating current > 3 A)
Ripple & Noise
≤ 1 mVrms (5 Hz to1 MHz)
Recovery Time
≤ 100 µs (50 % load change, minimum load
0.5 A)
Temperature
Coefficient
≤ 300 ppm/°C
Current
Regulation
Line
≤ 0.2 % + 3 mA
Load
≤ 0.2 % + 3 mA
Ripple & Noise
≤ 3 mArms
Tracking
Operation
Tracking Error
≤ 0.1 % + 10 mV of Master (No Load,
with load add load regulation ≤100 mV))
Parallel
Regulation
Line: ≤ 0.01 % + 3 mV
Load: ≤ 0.01 % + 3 mV
(rating current ≤ 3 A)
Load: ≤ 0.02 % + 5 mV
(rating current > 3 A)
Ripple & Noise
≤ 1 mVrms (5 Hz to 1 MHz)
Series Regulation
Line: ≤ 0.01 % + 5 mV
Load: ≤ 100 mV
Ripple & Noise
≤ 2 mVrms (5 Hz to 1 MHz)
OVP
Range
CH1/CH2: OFF, ON (1 V to 36 V)
CH3: OFF, ON (1 V to 6 V) (GPE-4323A)
CH4: OFF, ON (1 V to 16 V)(GPE-4323A)
Resolution
1 V
Accuracy
≤ ±1 V
