GPE-1326A/2323A/3323A/4323A Series User Manual
38
CH1/CH2 Series Tracking Mode
Background
Series tracking operation allows the GPE-
2323A/3323A/4323A to combine the output by
internally connecting CH1 (Master) and CH2
(Slave) in series. CH1 (Master) controls the
combined output voltage/current level which is
set independently.
The following describes two types of
configurations, depending on how common
ground is used.
Series Tracking without Common Terminal
Connection
Output rating
0 V to 64 V / 0 A to 3 A
+ -
Load
