GPE-1323/GPE-1205 User Manual
24
Background
Before connecting the output terminals to a load,
the wire gauge of the cables should be
considered.
It is essential that the current capacity of the load
cables is adequate. The rating of the cables must
equal or exceed the maximum current rated
output of the instrument.
Recommended
wire gauge
Wire Gauge
Nominal Cross
Section
Maximum
Current
28
0.1
3
26
0.15
4
24
0.25
5
22
0.35
7
20
0.55
9
18
1
12
The maximum temperature rise can only be 60
degrees above the ambient temperature. The
ambient temperature must be less than 30 degrees.
Output Terminals
Background
Before connecting the output terminals to the load,
first consider whether voltage sense will be used,
the gauge of the cable wiring and the withstand
voltage of the cables and load.
Warning
Dangerous voltages. Ensure that the power to the
instrument is disabled before handling the power
supply output terminals. Failing to do so may lead
to electric shock.
Steps
1. Turn the power switch off.
2.Connect the test lead includes in the accessory
parts to front panel output terminal.
3.Fix the load cables firmly to eliminate loose
connections from the front output terminals and
load cables.
