6.2 Connection on the AC Side
Ÿ Do not place inflammable and explosive materials around the WIT
Inverter.
Ÿ High voltages may cause electric shocks and serious injury. Please do
not touch the inverter in operation.
Ÿ Only qualified and trained electrical technicians are allowed to
perform operations. Technicians must observe instructions in this
manual and local regulations.
Ÿ Before connecting cables, ensure that the DC switches on the WIT
Inverter are OFF. Turn off the switches and breakers on the AC side and
the battery side. Otherwise, the high voltages of the WIT Inverter may
result in electric shocks.
Ÿ Each WIT Inverter must be equipped with an AC circuit breaker.
Multiple WIT Inverters cannot connect to the same AC circuit breaker
(not applicable to off-grid mode).
Ÿ Please do not connect loads between the WIT Inverter and the circuit
breaker.
Ÿ After connecting the cables, apply the fireproof mud evenly on the
waterproof silica gel pad inside the AC junction box to prevent water
from entering into the box.
Ÿ If the cable is thick, do not shake the cable terminals after tightening
them. Otherwise, the loose connection may cause overheating that
will damage the device. Ensure that the terminals are properly
connected before powering on the WIT Inverter.
1> Ensure the grid voltage and the grid frequency are within the acceptable range;
Preparation:
2> Disconnect the DC switches and the breakers on the AC side and the battery side.
A circuit breaker needs to be installed on the AC side, ensuring a safe disconnection
between the WIT Inverter and the upstream input when an exception occurs.
The circuit breaker on the AC side:
Device type
Rated voltage of the circuit
breaker
Rated current of the circuit
breaker
WIT 50K-A/-H
400V
150A
WIT 63K-A/-H
400V
150A
WIT 75K-A/-H
400V
200A
WIT 100K-A/-H
400V
200A
27
1. Recommended circuit breaker specifications for WIT 50-100K-A and WIT 50-100K-H
models.
2. Recommended circuit breaker specifications for WIT 50-100K-AE, WIT 50-100K-AU,
WIT 50-100K-HE and WIT 50-100K-HU models.
Device type
Rated voltage of
the circuit breaker
Rated current of
the circuit breaker
on the grid side
the circuit breaker
on the load side
Rated current of
WIT 50K-AE/-AU/-HE/
-HU
400V
300A
150A
-HU
WIT 63K-AE/-AU/-HE/
400V
300A
150A
-HU
WIT 75K-AE/-AU/-HE/
400V
400A
250A
-HE/-HU
WIT 100K-AE/-AU/
400V
400A
250A
Recommended power cable specifications:
1. Recommended AC power cable specifications for WIT 50-100K-A and WIT 50-100K-H
models.
Device type
Recommended cable specification
WIT 50K-A/-H
2
35mm
WIT 63K-A/-H
2
35mm
WIT 75K-A/-H
2
70mm
WIT 100K-A/-H
2
70mm
2. Recommended AC power cable specifications for WIT 50-100K-AE, WIT 50-100K-AU,
WIT 50-100K-HE and WIT 50-100K-HU models.
Device type
Recommended cable
specification on the grid
side
Recommended cable
specification on the load
side
WIT 50K-AE/-AU/-HE/-HU
2
95mm
2
35mm
WIT 63K-AE/-AU/-HE/-HU
2
95mm
2
35mm
WIT 75K-AE/-AU/-HE/-HU
2
150mm
2
70mm
WIT 100K-AE/-AU/-HE/-HU
2
150mm
2
70mm
NOTE: The wires should be tinned and are not frayed or cracked.
AC side connection steps:
2. Connect a ground cable to the copper grounding bar in the AC junction box. Fig 6.2
shows the position of the grounding bar inside the AC junction box;
1. Open the cover of the AC junction box. The position of the cover is shown in Fig 6.2;
3. Connect the main power cables according to the label. Fig 6.2 shows the position of the
label and the AC terminals.
28
DANGER
WARNING
