2.3 Safety instructions
1.Please read this manual carefully before installation.If you fail to install according
to the instructions in this manual,or ignore the warnings in the manual and the
equipment is damaged,our company reserves the right not to guarantee the quality;
2.All operations and wiring should be finished by the professional electrical or mechanic-
al engineers;
3.During installation,except for the wiring terminals,please do not move other parts
inside the chassis;
4.All electrical installations must comply with local electrical safety standards;
5.If the machine needs maintenance,please contact the local designated system
installation and maintenance personnel;
6.The use of this machine for grid-connected power generation requires permission
from the local power supply department;
2.2 Qualification of skilled person
This AC coupled inverter system operates only when properly connected to the AC
distribution network. Before connecting the MOD TL3-XA to the power distribution
grid, contact the local power distribution grid company. This connection must be made
only by qualified technical personnel to connect, and only after receiving appropriate
approvals, as required by the local authority having jurisdiction.
Ø Grounding the PV modules： MOD TL3-XH is a transformerless
inverter. which means there is no galvanic separation. Do not
grounding the DC side of the MODTL3-XH inverter. Only
grounding the mounting frame of the photovoltaic module.
Otherwise there will be an error message "PV ISO Low".
Ø Comply with the local requirements for grounding the PV
modules and the PV generator. GROWATT recommends
connecting the generator frame and other electrically conductive
surfaces in a manner which ensures continuous conduction with
ground in order to have optimal protection of the system and
personnel.
CAUTION
2.3.2 Electrical Connection Warnings
Ÿ Do not open the inverter except the wire box by qualified persons.
Ÿ Electrical installation, repairs and conversions may only be carried
out by electrically qualified persons.
Ÿ Forbid live line work.
Ø Danger to life due to high voltages in the inverter
Ø Persons with limited physical or mental abilities may only work
with the Growatt inverter following proper instruction and under
constant supervision. Must keep the Growatt inverter away from
children.
Ÿ There is residual voltage in the inverter after the device shutdown.
The inverter need to take 20 minutes to discharge for safety.
Ø The components in the inverter are live. Touching live components
can result in serious injury or death.
DANGER
Ø Make all electrical connections (e.g. conductor termination,
fuses, PE connection, etc.) in accordance with prevailing
regulations. When using the inverter to provide the power,
adhere to all prevailing safety regulations to minimize risk of
accidents.
Ø Systems with inverters typically require additional control (e.g.,
switches, disconnects) or protective devices (e.g., fusing circuit
breakers) depending upon the prevailing safety rules.
WARNING
5
6
Ø Before installation, pleae check the unit to ensure that there is no
transportation or handling damage, which may affect the
insulation integrity or safety clearances; otherwise, it may cause
safety hazards.
Ø Follow the instructions in this manual to assemble the inverter.
Note that select the suitable mounting location and comply with
the specified requirements of cooling.
Ø Unauthorized removal of necessary protections, improper use,
incorrect installation and operation may lead to serious safety and
shock hazards and/or equipment damage.
Ø In order to minimize the possibility of shock hazards due to
dangerous voltages, cover the entire solar array with dark colored
materials before connecting the array to any equipment.
WARNING
2.3.1 Assembly Warnings
2.3.3 Operation Warnings
CAUTION
WARNING
Ø Ensure all connectors are sealed and secure during operation.
Ø Although designed to meet all safety requirements, some parts
and surfaces of inverter are still hot during operation. To reduce
the risk of injury, do not touch the heat sink at the back of the PV-
inverter or nearby surfaces while inverter is operating.
Ø Incorrect sizing of the PV panels may result in voltages being
present which could destroy the inverter. The inverter display will
read the error message “PV voltage High!”
Ø All operations regarding transport, installation and start-up,
including maintenance must be operated by qualified, trained
personnel and in compliance with all prevailing codes and
regulations.
Ø When the inverter is disconnected from the grid, please be careful
because some components can retain enough charge to create a
shock hazard. In order to minimize the occurrence of this
situation,observe all corresponding safety symbols and marks in
this manual.
Ø Under special circumstances, the inverter may be subject to
electromagnetic interference from surrounding equipment. At this
time, the user is obliged to take correct measures to reduce the
interference from surrounding equipment to the inverter.
Ø Do not stay close to the inverter less than 20cm at any time.
