When the inverter leaves the factory, the grid-connected voltage and frequency are
set in accordance with the latest domestic standard;
If the grid voltage is lower to or higher than the domestic legal requirements, the
inverter cannot be connected to the grid. After obtaining the permission of the local
power operator, the user can choose other voltage levels according to the voltage
situation of the grid connection point.
Tips and disclaimers
Excessive grid voltage may affect the normal use and service life of home
appliances on the grid-connected side,or cause loss of power generation.
Our company does not accept any responsibility for the related impacts
and consequences caused by enabling the automatic control function of
output voltage to connect to the grid.
9.3.3 Check firmware version,Region,Country/Area and Power Quality Response
Modes (Australia model only)
Single touch to switch display.
Double touch to enter next stage menu.
Grid
XXXvXXXHz
Etotal
XXXXw
Etoday
XXXkWh
Power
XXXXw
More Info
Model:S03B00D
00T00P00U00M0
000
Set parameter
PV3
XXXvXXXXw
PV2
XXXvXXXXw
PV1
XXXvXXXXw
Double
touch
FW Ver:AM X.X
Country/Aera
Australia
Region:
A/B/C/NZ
Power quality:
Volt-Var
9.3.2 Enabling/Disabling Power Quality Response Modes(PQRM)
(Australia model only)
Information
PQRM setting
Ø When the Region setting is completed, the inverter will operate
under default mode different from region.
MIN TL-X contains five types Power Quality Response Modes：
Volt-Var,Volt-watt, Fixed PF, Reactive power, Power limit. If you want to change the
Power Quality Response Modes please refer to chapter 7.3.1.
9.3.4 Check firmware version,Region,Country/Area and Power Quality Response
Modes (Australia model only)
The inverter power output will vary in response to the AC grid voltage. This is switched
on by default.This function belongs to advanced function, if you need to change,
please contact the after-sales operation and maintenance to make adjustments.
Reset Country
Country/Aera
VDE0126
Country/Aera
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Reset Region
Set Region
A B C
NO
YES
Set OK
Set parameter
General
Advanced
Password
***
Reset PQRM
Set PQRM
Volt-Var
Set PQRM
xxxxxxx
Set OK
Set parameter
General
Advanced
Password
***
Set Region
A B C
Country/Aera
Australia
Set PQRM
Disable Enable
