29
30
7.3.3.1 Select Protection Voltage Level
All settings interface is as follows:
The inverter is factory set to CQC standard regulations, customers can choose different
voltage protection levels according to the actual situation; single touch switching
voltage level, continuous touch twice to confirm the setting.
0 wide voltage is disabled
1 wide voltage level 1
2 wide voltage level 2
Figure 7.7
Figure 7.6
Tips and Disclaimers
7.3.3.2 Language Setting
7.3.3.4 Set Date and Time
7.3.3.3 Set the COM Address
The grid voltage and frequency of the inverter are set according to NB/T 32004-2013 or
the latest domestic standard.
If the grid voltage is close to or higher than the domestic regulations, the inverter cannot
be connected to the grid and the local power operator can obtain the voltage level.
According to the voltage of the grid connection point, the user can select other voltage
levels.
Excessive voltage of the power grid may affect the normal use and
service life of the household appliances on the grid side, or cause loss
of power generation. Due to the related effects and consequences
caused by the integration of the output voltage automatic control
function, we do not recognize any responsibility
The default language is Chinese, press the touch twice to enter the setting mode, switch
the language with a single touch, and touch the setting twice to confirm the setting.
Set Language
English
English
Chinese
Set OK
The default COM address is 1, continuous touch twice to enter the setting mode, single
touch, number +1, continuous touch twice to confirm the setting, long press for 5S and
the value will restore to 1.
Set Comaddr
1
Set Comaddr
2
Set OK
Touch twice to enter the parameter setting submenu, select the general setting, press
twice to enter the general setting submenu, single touch to switch the display interface,
touch the date and time interface twice to enter the setting state, single touch, number +
1, press twice to confirm the setting, long press 5s to reset to the default value.
After the storage time exceeds one month, the time and date set by the
inverter may be incorrect. The inverter needs to be set before it is
connected to the grid.
Figure 7.8
Figure 7.9
WARNING
Wi d e Volt Set
0 1 2
Pa s s word
12 3
En a b le|Nli n e
Ex p o rlimit
OF F ON
Ge n e ral
Ad v a nced
Se t D a te
20 1 8-12-14
Se t T i me
12:30:30
Se t C o maddr
1
Se t L a nguage
En g l ish
Ge n e ral
Ad v a nced
Se t
Par a m eter
Re s et factor y
YE S N O
WideV olt Set
WideV olt Set
0 1 2
Set OK
