Page 33 of 48 S1047.mz-16-V1.0-EN
Both the control characterisƟcs in the submenu Control Set in the basic
menu as well as virtually all mixer programming is essenƟĂůůLJdone in the
same way. The corresponding procedure is shown below with reference to
the throƩle curve.
However, the seƩings shown have a purely demonstraƟǀĞ purposes only
and do not represent real throƩle behavior!
Selecting a Curve
1. Enter the desired submenu.
Here is an example of the submenu “Control Set”.
2. On the desired channel touch the detail icon in the “Detail” column
for example, throƩle.
The display shown on the leŌ will show which is the Basic menu.
3. Tap on the “Other” ĮĞůd in the upper right corner.
The display shown on the leŌ will show which is the Other menu
4. Tap on the “Curve type” icon to select a curve.
Each tap will show a diīerent curve type
The choices are:
ͻ A linear characterisƟc without points between the endpoints. This
characterisƟc corresponds to the standard seƫng.
ͻ A linear characterisƟc with 5 points evenly distributed between
the endpoints. This characterisƟc is to be selected as the basis of
non-linear characterisƟcs.
ͻ A horizontal curve with a single point in the middle of the control.
The horizontal characterisƟc curve can only be moved verƟcally
and used, for example as a control oīset for a channel for throƩle
curves or Ňŝght controller seƫngs.
5. If needed you can tap on the “Spline” icon which determines if the
curve should be “square” or “curved”.
Seƫng Controls and Mixers
