Page 21 of 48 S1047.mz-16-V1.0-EN

SeƫŶg date and Ɵme

Date & Time

In this display, the current date and Ɵme is entered or corrected as part of

the iniƟĂů setup of the transmiƩer.

1. Tap on the desired value Įeld. This is displayed in white and selecƟon

Įelds are displayed at the boƩom of the display.

2. Use the up "↑" or down " ↓" buƩons to select the desired value.

3. If necessary, proceed similarly with the other value Įelds.

4. Touching the check buƩon closes the current display and switches

to the last one.

Touching "Ok" restarts the transmiƩer and aŌer startup the factory

preconĮgured Įrst home page appears.

M

ain Menu

The main display is designed around user editable display widgets that can

be changed and adapted to your own personal needs. There are in total six

editable decks that can be accessed with the leŌ/right arrow keys on the

radio.

InstrucƟons for creaƟŶg and modifying decks can be found in the help menu

or by following our online video tutorials.

S

ystem Help

Accessing the context sensiƟǀe help is done in each menu by tapping the

top right ?

of the display. If required, such help pages can also be created

and stored by the user in the appropriate directory:

To create your own help page, you can use any paint program such as

“Paint” or that comes standard with Windows 10 or Publisher which is part

of the Oĸce product suite. There is also a free downloadable version from

the MicrosoŌ Store called Paint 3D.

Pages should be in landscape format sized at 440 x 232 pixels. AŌer creaƟŶg

any type of content, save it in "BMP image" format under "Save as" with the

Įůe type "24-bit bitmap (* .bmp; *. Dib)". In Paint 3D, under "Save as Įůe"

select "Others" and then as storage format "2D-Bitmap (* . bmp)". The

storage locaƟon is the corresponding subdirectory of the "Help" directory of

the transmiƩer and the Įůe name is the next free three-digit number.
