Page 15 of 48 S1047.mz-16-V1.0-EN

DATA Connection

COM Connection

DSC Connection

Micro USB Connection

Charging the

TransmiƩer

The DATA connecƟon is suitable for connecƟon of a smart box or an external

module. If necessary, this port can also be switched to out- put a digital

SUMD digital signal.

The corresponding seƫŶgs are made in the submenu "I/O conĮg." of the

system menu, see below under DSC connecƟon.

Serial interface for future use

Through a DSC cable this port can be used for a simulator or for wired

Teacher/Student mode.

If necessary, switch to the required DSC operaƟŶg mode in the "I/O ConĮg."

submenu of the system menu.

To ensure a correct DSC connecƟon, observe the following

1. Perform any necessary seƫŶgs in the menu.

2. Connect one end of the DSC cable in the DSC port of the switched

oī transmiƩer and the other end to the device to be connected.

3. Turn the transmiƩer on.

The USB cable supplied with the transmiƩer is plugged into this socket.

N

ote

Once connected to a PC or other USB power source, a yellow LED should be

lit solidly to the leŌ of the

mz-16 HoTT

's micro-USB port. If this LED ŇĂshes

yellow or is even dark, the power source is too weak to charge the

transmiƩer.

T

ransmitter switched off

Once the transmiƩer is connected to a suitable USB power source the

charging process begins.

Depending on the current charge status of the transmiƩer baƩery, the bezel

of the ON / OFF switch will ŇĂsh approximately every 2 seconds in diīerent

colors and with varying frequency. As soon as the bezel glows solid green,

the baƩery is fully charged. The charging process is complete.
