9
- Power tools must be started up before the cutter comes into contact with
the workpiece. Otherwise there is a danger of kickback, as the tool used
will lock into the workpiece.
- Ensure that all locking clamps are tightened.
- Never attach work tools to the power tool other than those recommended
by the manufacturer.
- When replacing the cutter, ensure that its shank is fixed at a depth of at
least 20 mm.
- Before milling, make sure there is clearance under the workpiece to
prevent the cutter coming into contact with other workpieces.
- The surface of the work area must be inspected. You need to make sure
that there are no unwanted foreign materials (nails, screws, etc.).
- Do not leave a switched-on milling machine unattended.
- When the power tool is not in use, it should always be unplugged by
removing the battery pack and stored in a childproof place.
- Always unplug the power tool by removing the battery pack before
changing the work tool or carrying out any adjustment, maintenance or
operation.
- Do not use any solvents to clean the power tool, which could damage
plastic parts.
ATTENTION: The device is intended for indoor operation. Despite the
inherently safe design, the use of safety measures and additional
protective measures, there is always a risk of residual injury during
operation.
PICTOGRAMS AND WARNINGS
Read the operating instructions, observe the warnings and safety
conditions contained therein!
The product meets the requirements of the standards and
directives in force in the European Union
Personal protective equipment, safety goggles, dust mask, and ear
defenders must be worn when working.
Wear protective gloves when working
Do not dispose of the device with household waste
Protect from children
Protect against moisture
Before any repair, maintenance, the unit must be disconnected
from the power supply by removing the battery.
DESCRIPTION OF THE GRAPHIC ELEMENTS
The following numbering refers to the components of the device
shown on the graphic pages of this manual.
Designation
Description
Fig. A
1
Milling machine body
2
Milling machine body holder
3
Slide lock knob
4
Battery socket
5
Milling depth adjustment knob
6
Locking of the router body in the chuck
7
Milling depth scale
8
Milling machine foot
9
Switch
10
Speed change button
11
Dust extraction and guard attachment knob
Fig. B
1
Spindle speed indicator
2
Milling machine switch
3
Speed change button
4
Spindle lock
5
Spindle
6
Cutter clamping nut
* There may be differences between the graphic and the actual
product
PROPER BATTERY HANDLING AND OPERATION
• The battery charging process should be under the control of the user.
• Avoid charging the battery at temperatures below 0°C.
• Only charge the batteries with the charger recommended by the
manufacturer. The use of a charger designed to charge a different type
of battery poses a risk of fire.
• When the battery is not in use, keep it away from metal objects such as
paper clips, coins, keys nails, screws, or other small metal items that
can short-circuit the battery terminals. Short-circuiting the battery
terminals can cause burns or fire.
• In the event of damage and/or misuse of the battery, gases may be
released. Ventilate the room, consult a doctor in case of discomfort. The
gases may damage the respiratory tract.
• Fluid leakage from the battery can occur in extreme conditions. Liquid
leaking from the battery can cause irritation or burns. If a leak is
detected, proceed as follows:
• Carefully wipe off the liquid with a piece of cloth. Avoid contact of the
liquid with the skin or eyes.
• if the liquid comes into contact with the skin, the relevant area on the
body should be washed immediately with copious amounts of clean
water, or neutralise the liquid with a mild acid such as lemon juice or
vinegar.
• if the liquid gets into the eyes, rinse them immediately with plenty of
clean water for at least 10 minutes and seek medical advice.
• Do not use a battery that is damaged or modified. Damaged or modified
batteries may act unpredictably, leading to fire, explosion or danger of
injury.
• The battery must not be exposed to moisture or water.
• Always keep the battery away from a heat source. Do not leave it in a
high temperature environment for long periods of time (in direct
sunlight, near radiators or anywhere where the temperature exceeds
50°C).
• Do not expose the battery to fire or excessive temperatures. Exposure
to fire or temperatures above 130°C may cause an explosion.
NOTE: A temperature of 130°C can be specified as 265°F.
• All charging instructions must be followed, and the battery must not be
charged at a temperature outside the range specified in the rating data
table in the operating instructions. Charging incorrectly or at
temperatures outside the specified range can damage the battery and
increase the risk of fire.
BATTERY REPAIR:
• Damaged batteries must not be repaired. Repairs to the battery are only
permitted by the manufacturer or an authorised service centre.
• The used battery should be taken to a disposal centre for this type of
hazardous waste.
SAFETY INSTRUCTIONS FOR THE CHARGER
• The charger must not be exposed to moisture or water. The ingress of
water into the charger increases the risk of shock. The charger may
only be used indoors in dry rooms.
• Unplug the charger from the mains before carrying out any
maintenance or cleaning.
• Do not use the charger placed on a flammable surface (e.g. paper,
textiles) or in the vicinity of flammable substances. Due to the charger's
temperature increase during the charging process, there is a danger of
fire.
• Check the condition of the charger, cable and plug each time before
use. If damage is found - do not use the charger. Do not attempt to
disassemble the charger. Refer all repairs to an authorised service
workshop. Improper installation of the charger may result in a risk of
electric shock or fire.
• Children and physically, emotionally or mentally challenged persons, as
well as other persons whose experience or knowledge is insufficient to
operate the charger with all safety precautions, should not operate the
charger without the supervision of a responsible person. Otherwise
there is a danger that the device will be mishandled resulting in injury.
• When the charger is not in use, it should be disconnected from the
mains.
• All charging instructions must be followed, and the battery must not be
charged at a temperature outside the range specified in the rating table
in the operating instructions. Charging incorrectly or at temperatures
outside the specified range can damage the battery and increase the
risk of fire.
CHARGER REPAIR
• Do not repair a defective charger yourself. Repair of the charger is only
permitted by the manufacturer or an authorised service centre.
