Gossen Metrawatt GmbH 9
4.1.2 Measuring Insulation Resistance with
the PROFITEST PRIME
Preparing for Measurement
➭ Using the corresponding test probes,
connect the test instrument to the L, N
and PE sockets at the test adapter.
➭ Disconnect the system from all sources
of voltage before connecting the mea-
suring points to the test adapter.
➭ Connect the system to sockets L1, L2,
L3, N and PE.
Performing the Measurement
ATTENTION!
!
Insulation test voltage may not ex-
ceed 500 V.
➭ Perform the measurement as described
in the operating instructions for the test
instrument:
PROFITEST PRIME: sections 8.6 and 11
➭ The following measuring functions are
available for the measurement of insula-
tion resistance: insulation measurement
with constant voltage and insula-
tion measurement with rising test voltage
.
Overview of Connected Conductors
The red illuminated LEDs in the connections
overview indicate the respectively connected
conductors.
Continuity, PRIME
RISO
Test
Sequence
R
INS
LED Displays (red)
01/11 N-PE LED4 + LED11
02/11 L1-PE LED1 + LED11
03/11 L2-PE LED2 + LED11
04/11 L3-PE LED3 + LED11
05/11 L+N-PE
LED1 + LED2 +
LED3 + LED4 +
LED11
06/11 L1-N LED1 + LED10
07/11 L2-N LED2 + LED10
08/11 L3-N LED3 + LED10
09/11 L1-L2 LED1 + LED8
10/11 L2-L3 LED2 + LED9
11/11 L1-L3 LED1 + LED9
PROFITESTREMOTE Measurements
