The Instrument

4.7 Technical Data

Terminals – test outlets

Earth contact

IN4:

1P+N+PE, 0.8 A,

230 V

3P+N+PE IN2/OUT2:

0.8 A, 400 V

Power Supply

Nominal line voltage 230/400 V 50 Hz

Mains connection

Single-phase via

recessed

power receptacle:

230 V 1P+N+PE 16 A

3-phase via ISO

adapter:

230/400 V 3P+N+PE

16 A

Throughput rating Earth contact: 20 VA

CEE: 60 VA

Power consumption

Earth contact: < 3 VA

CEE: < 6 VA

Electrical Safety

Measuring category 300 V CAT II

Pollution degree 2

Fuse links Supply network:

Single-phase (N1):

FLN: 2 × F0,8A/

250V, 5 × 20 mm

3-phase (N2):

F1, F2 and F3:

3 ea. F0.8A/500V,

6.3 x 32 mm

Ambient Conditions

Operating temperature

–5 … +50 C

Storage temperature –20 … +60 C

Relative humidity

Max. 75 %, no con-

densation allowed

Mechanical Design

Protection Housing: IP40

(protection against

ingress of solid for-

eign objects:

 1.0 mm diameter,

protection against

ingress of water:

not protected)

Termi nals IP20

(protection against

ingress of solid for-

eign objects:

 12.50 mm diame-

ter, protection against

ingress of water:

not protected)

per DIN EN 60529 /

IEC 60529

Dimensions

Housing (W × H × D):

Approx. 401 × 307 ×

173 mm

(without connector

cable, with surface

mount sockets)

Weight Approx. 4.6 kg

(incl. connector

cable)

4.8 Characteristic Values

Measurement/test with METRACLIP 61 current

clamp:

Protective conductor

current measurement

Measuring range:

0mA…30mAAC

Measurements/tests with compatible test instru-

ment:

Protective conductor

measurement see technical data on

function of the

test instrument

Insulation

measurement see technical data on

ISO

function of the

test instrument
