Measuring RC (Testing of Resistance Coding) (not possible with SECUTEST ST PRO)

9 Measuring R

(Testing of Resistance Coding)

(not possible with SECUTEST ST

PRO)

Testing of specified resistance value R

for

maximum current-carrying capacity of the

mode 2/3 charging cable per

DIN EN 61851-1 (VDE 0122-1)

Additionally, you require a standards-compli-

ant resistance measuring instrument.

➭ Connect the

test object

as described in

chapter 5.3.

➭ Measure resistance between the PP and

PE sockets at ICCB-OUT1 with a stan-

dards-compliant measuring instrument.

➭ Compare the measured resistance value

with the value indicated in the table

below (Table B3 off DIN EN 61851-1).

Note

Observe the maximum current-carry-

ing capacity specified on the cable.

10 Storage and Transport

Attention!

Improper Storage

Damage to the product and measur-

ing error due to environmental influ-

ences

Store the instrument in a protected

location and only within the limits of

permissible ambient conditions. The

respective ambient conditions (tem-

perature, humidity etc.) can be found

under “Technical Data” on page 9.

Note

If the test adapter has not been used

for a long period of time, the switches

may demonstrate increased contact

resistance depending upon storage

conditions.

If this is the case, actuate the

switches several times.

Attention!

Improper Transport

Damage to the product and measur-

ing error

Transport the instrument only within

the limits of permissible ambient con-

ditions (temperature, humidity etc.).

See “Technical Data” on page 9.

Vehicle state Function Test Result

Testing of resis-

tance coding for

vehicle inlets and

vehicle connec-

tors per

IEC 61851

Table B.3

Resistance

measure-

ment

with multi-

meter or

test instru-

ment

13 A charging cable,

1.5 k 

20 A charging cable, 680



32 A charging cable, 220



63 A charging cable, 100


