DUST CONTAINER AND FILTERS

Dust container and filters

To clean the dust container, remove the handheld vacuum cleaner from the housing. // On the

handpiece, press both buttons on the bottom of the container at the same time. // First, remove the

bottom part and pull the containers from the hand vacuum cleaner at an angle. // Pull the filter with the

sleeve out of the dust container. // Pull the filter out of the filter sleeve with a mesh // The container,

sleeve and filter can be wiped, shaken or rinsed with lukewarm water, but be careful, as improper

handling can damage parts of the vacuum cleaner. // Ensure that all parts are completely dry before

reinstalling the container back onto the appliance. // Reinstall the container with the sleeve and filter

by first pushing the container at an angle under the upper part of the handheld vacuum cleaner and

then pressing the lower part into the lower part // Never vacuum without the dust filter inserted.

Replacing the filter

If you notice that the filter is damaged, replace it immediately. With regular use, we recommend

replacing the filter every 6 months to ensure the longest life of the vacuum cleaner.

Motorised brush

Floor brush

There is a push button on the side of the brush that releases the pin on the roller. // Simultaneously

press the push button and lift the plastic pin of the roller with your finger. // Carefully cut along the

recess on the roller using scissors or another sharp object to remove the fabric or hair that is caught

on the roller. // Do not pull on the accumulated waste as it may damage the bristles on the roller. //

Replace the roller by fitting the side of the roller correctly back into the slot and fixing it back into the

brush. // The roller is correctly positioned when you hear it lock.

Cleaning brush for textile surfaces

There is a push button on the side of the brush that releases the pin on the roller. // Carefully cut along

the recess on the roller using scissors or another sharp object to remove the fabric or hair that is caught

on the roller. // Do not pull on the accumulated waste as it may damage the bristles on the roller. //

Replace the roller by fitting the side of the roller correctly back into the slot and fixing it back into the

brush. // The roller is correctly positioned when you hear it lock and securely lock the roller back into

the brush with the pin.

DISPOSAL OF THE APPLIANCE

If you want to replace the appliance or no longer need it, you should also think about protecting the

environment.

The battery can only be removed when you want to discard the product.

Please follow the instructions below when removing the battery and observe all safety precautions:

Unplug the appliance. // The battery must be completely discharged before removal. // Follow the

attached pictorial instructions. // Cut the wires closest to the battery one by one and remove the battery.

// Do not cut both wires at the same time to avoid short-circuiting. Although the battery is empty,

improper disposal may result in short-circuiting, which may cause smoke, smouldering, or even fire.
