For easier transport, some appliance parts are packed separately and safely placed in the main packaging unit.

// Before first use, read and follow the instructions for assembly and safe use. // The appliance is intended for

dry vacuuming in a domestic environment.

PARTS

1

Vacuum cleaner handle and housing

2

Handheld vacuum cleaner

3

Motorised floor brush

4

Adapter with power cord

5

Stand

6

Bristle brush

7

Narrow nozzle

Accessories depending on the package you

purchased

8

Motorised brush for vacuuming textile surfaces

9

Floor cleaning nozzle with a wiping cloth

INSTALLATION

Lift the vacuum cleaner handle and place it on the floor brush. Insert the handheld vacuum cleaner first

into the slot at the bottom and then press the handle into the vacuum cleaner housing. The vacuum

cleaner is assembled properly when you hear a short click.

The vacuum cleaner stand is delivered in two parts. Attach the top part onto the bottom part. Before

use, check that it is firmly fixed to avoid subsequent damage to the vacuum cleaner. Connect the

adapter to the opening as shown in the figure. Charge the vacuum cleaner at least 1 m away from any

heating surfaces.

USE

The vacuum cleaner can be used with or without nozzles. See instructions below.

1

Connect the floor brush to the vacuum cleaner handle. It can be used to vacuum all floor surfaces

(dry floor surfaces).

2

Attach the narrow nozzle to the handheld vacuum cleaner. It is intended for vacuuming narrow

and inaccessible areas (corners, sofas, cobwebs, behind radiators...).

3

Attach the soft bristle nozzle to the hand-held vacuum cleaner. It is suitable for vacuuming all

sensitive surfaces.

4

Attach the bed nozzle to the handheld vacuum cleaner. It is suitable for vacuuming all textile

surfaces with short fibres.

5

Pour tap water (it must not be hot) into the floor washing nozzle. At the same time, wet the wiping

cloth, wring it out well and stick it to the bottom of the nozzle. Place the vacuum cleaner in the

designated slots. The wiping cloth can be washed at a maximum of 40 °C and is not suitable for

tumble drying. After washing, pour the water out of the container and dry the wiping cloth.

CHARGING

Place the vacuum cleaner correctly on the charging station. // For safety reasons, we recommend that

the appliance is at least 1 m away from any heating bodies during charging. // During charging, the

battery percentage will appear on the display unit. // The appliance cannot be switched on while

charging.

OPERATION

1

There is an on/off button on the vacuum cleaner handle.

The vacuum cleaner has 2 or 3 speeds depending on the model you purchased.

21.6 V - MAX (up to 24 min) // MIN (up to 55 min)

25.2 V - MAX (up to 26 min) // MIN (up to 60 min)

28.8 V - MAX (up to 28 min) // MED (up to 40 min) // MIN (up to 77 min)

2

Handheld vacuum cleaner only has one speed - MAX

3

The display shows the suction speed and the battery percentage
