BMT-P2/144A(550W)P28
STANDARD INSTALLATION MANUAL FOR POLARIS 580W (HOOP INSTALLATION)
Installation Engineering Process
Determine the cable run and AC/DC conduit requirement after on-site measurement
● Conduit is required for cables between array and inveer.
● Conduit is required for cables between inveer and distribution box, distribution box and
household electricity box.
Conduit laying requirements
● When laying electrical conduits on the wall, they should be laid in the corners of the wall, in
the same direction along rainfall pipes and air-conditioning pipes.
● It is advisable to avoid the crossover of AC and DC directions in the piping between
equipment.
Cable laying
Requirements for cable laying:
● When wiring each system, the type of conductor, voltage level, etc. are inspected according
to the provisions of the current national standards.
● Remove water and debris from the conduit or wire channel before threading.
● When using the crimping method to connect the wire, the specications of the terminal
copper sleeve crimp should be consistent with the cross-section of the cable core.
● AC and DC cables should be run in dierent conduits to ensure safety.
● After the cable is installed, the joints should be glued and sealed to prevent water from
seeping into the conduit. The opening of exposed conduits should be plugged with soft cloth
to avoid the ent of foreign objects.
● Cable bending radius ≥ 6D.
● Wiring through conduits to avoid high temperature heat generating objects as much as
possible.
● Conduits need to be secured by conduit clips.
● The AC and DC cables connected to the inveer and distribution box should to be marked
with the cable number at both ends.
DC side cable connector installation.
● Arrange cable connectors and pins according to their intended polarity.
● Strip the DC PV cable by using wire strippers according to the length of the copper core
pins.
● Inse the DC PV cable into the pins, and crimp the pins.
● Inse the pins into the male and female connectors and fasten them with the special
screwdriver.
● Plugging in the male and female cable connectors and test the tightness of the connection.
